QLO200 series
QLO229
IP55, Class I. Class II on request. IK10. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Polycarbonate main lens. Two cable entries. Integral EC electronic converter.
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK10 |
| Ingress Protection | IP55 |
| Finish | Powdercoat finish in RAL7016, RAL9004, RAL9006, RAL9007 or RAL9016 |
| Corrosion Protection | 5CE |
Electrical
| Ballast / Driver | Integral ECG control gear |
| Cable | Two cable entries |
| Power Supply | 220-240V / 50-60 Hz |
Additional Information
- - - -
| Item | Download |
|---|---|
| Product Images | |
| Photometrics | |
| Installation Instructions |
