FLC230-TW LED [GP]

Back
Standard Colours
Tunable White
Colour Changer
Family Spec Sheet
Adjustable rectangular light area Adjustable rectangular light area Frame Frame
Adjustable round spot area Adjustable round spot area Zoom Zoom
Freeform shape projection Freeform shape projection Gobo Gobo
10W18W44W

Profile Projector [GP] for projection of gobos on a surface. Spherical/triple flat convex lens system. Gobo motif on request, to be ordered separately. Tunable White Technology.
IP66, Class I. Class II on request. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland. Second gland for through wiring on request. PMMA LED lens array. Factory installed LED circuit board. LED board can be removed for upgrading. Integral EC electronic converter, thermally separated. DALI interface. Gobo outside diameter 86 mm, max. printable area d = 60 mm. WE-EF recommendation = d 48 mm.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberDALI
Kabel
Leistungsfaktor> 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz1/2 kV (optional SP10)

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h
Energy efficiency classE (Light source)

Lichtverteilung

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
139-2998_minsymmetric Gobo-Projector [GP] - min aperture angleLED-FT-32W / 450 mA - 2200-6000 K808.480EC11.10
139-2998_maxsymmetric Gobo-Projector [GP] - max aperture angleLED-FT-32W / 450 mA - 2200-6000 K952.280EC11.10
Showing 1 to 2 of 2 Entries
