AFL130-WL LED

Wild-Light. IP66, Class I or Class II. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. CCG® Controlled Compression Gasket. Non-reflecting flat safety glass cover, hinged. Integral EC electronic converter in thermally separated compartment. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. Wild-Light with Advanced or Motion available on request, must be specified at time of ordering. For further details and available variants see below under additional information – Wild-Light Presentation. The luminaire is factory-sealed and does not need to be opened during installation. Can be used as post top or side entry version. Specification at time of order is recommended. Spigot Ø 76 x 100 mm. Spigot Ø 60 x 100 mm or 42 x 100 mm optional available. Must be indicated during order placement. Contact WE-EF direct or your local WE-EF sales representative for an individual solution designed to precisely meet your needs. IMPORTANT Photometric data legend (for ies-data): Part ID (channel I+II - both colour temperatures 1850K (True Amber) + 2200K / 2200K + 3000K) Part ID_1 (channel I - lower colour temperature 1850K (True Amber) / 2200K only) Part ID_2 (channel II - upper colour temperature 2200K / 3000K only) Photometric data legend (for ldt-data): Part ID (channel I+II - both colour temperatures 1850K (True Amber) + 2200K / 2200K + 3000K) Part ID (channel I - lower colour temperature 1850K (True Amber) / 2200K only) Part ID (channel II - upper colour temperature 2200K / 3000K only) Photometric files (IES, LDT) for light distributions [S61] [S65] [S66] [S70] [R60] [R61] [P66] [Q66] [A61] with Backlight Shield on request.
