IP67*, Class I. Class II on request. IK08. Marine-grade all aluminium construction. Anodized aluminium extrusion. PCS hardware. Silicone rubber gasket. Safety glass lens. Luminaire can be driven over at low speed, without accelerating or turning, by vehicles with air-filled tyres, at a weight up to 5 tonnes per wheel. Max. static load, 3 tonnes (according to DIN EN 60598-2-13). Factory-sealed termination chamber complete with cable gland and 0.5 m of flexible cable, including sealable junction box SJB. Linear PMMA LED lens. Factory installed LED circuit board. LED board can be easily removed for upgrading. Luminaire is factory sealed and does not need to be opened during installation. Integral electronic converter with DALI interface in thermally-separated compartment. Luminaires with [LB/IW] [LM/IW] and [LE/IW] light distribution are supplied with honeycomb shield IW to reduce stray light. Optional 2200 K version available. To be specified at time of ordering. Eco Step Dim® on request. The optional installation blockout is recommended for mounting. To be ordered separately. The luminaire is not suitable for permanent underwater operation and must be switched off in the event of flooding. * Additionally tested to IP66, IP67, IP68 0.1 bar 3h, up to 1 m depth according to DIN EN 60598 and IP69K/80° according to DIN EN 60529.

ETV120 LED Schematics
Colors
Material

Body: Marine-grade all aluminium construction. Anodized aluminium extrusion.

Fasteners: PCS polymer coated stainless steel

Gasket: Silicone rubber gasket

Impact Protection: IK08

Ingress Protection: IP67

Finish:

Corrosion Protection:

Mounting: Installation blockout (for single or multiple luminaire configuration) required, to be ordered separately.

Electrical

Ballast / Driver: DALI

Cable: 0.5 m of flexible cable

Power Factor: > 0.9

Power Supply: 220-240V / 50-60 Hz

Surge Protection: 1/2 kV

Additional Information

Lifetime: Ta=25° L90B10 > 90000h

Energy efficiency class: D (Light source)

:

Light Distribution

Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
186-0236symmetric linear, wide beam [LB]LED-32/20W / 225 mA - 3000 K1915.780
186-0237symmetric linear, wide beam [LB]LED-32/20W / 225 mA - 4000 K1915.780
186-0239symmetric linear, medium beam [LM]LED-32/20W / 225 mA - 3000 K2140.480
186-0240symmetric linear, medium beam [LM]LED-32/20W / 225 mA - 4000 K2140.480
186-0242symmetric linear, narrow beam [LE]LED-32/20W / 225 mA - 3000 K2101.380
186-0243symmetric linear, narrow beam [LE]LED-32/20W / 225 mA - 4000 K2101.380
186-0245symmetric linear, very narrow beam [LEE]LED-32/20W / 225 mA - 3000 K2405.980
186-0246symmetric linear, very narrow beam [LEE]LED-32/20W / 225 mA - 4000 K2405.980
186-0248asymmetric linear, wallwash [LA10]LED-32/20W / 225 mA - 3000 K2049.880
186-0249asymmetric linear, wallwash [LA10]LED-32/20W / 225 mA - 4000 K2049.880
186-0436symmetric linear, wide beam [LB]LED-32/20W / 225 mA - 2700 K1915.780
186-0347symmetric linear, medium beam [LM]LED-32/20W / 225 mA - 2700 K2140.480
186-0438symmetric linear, narrow beam [LE]LED-32/20W / 225 mA - 2700 K2101.380
186-0439symmetric linear, very narrow beam [LEE]LED-32/20W / 225 mA - 2700 K2405.980
186-0440asymmetric linear, wallwash [LA10]LED-32/20W / 225 mA - 2700 K2049.880
186-0477symmetric linear, wide beam [LB/IW]LED-32/20W / 225 mA - 2700 K851.580
186-0384symmetric linear, wide beam [LB/IW]LED-32/20W / 225 mA - 3000 K851.580
186-0385symmetric linear, wide beam [LB/IW]LED-32/20W / 225 mA - 4000 K851.580
186-0387symmetric linear, medium beam [LM/IW]LED-32/20W / 225 mA - 4000 K1068.880
186-0479symmetric linear, narrow beam [LE/IW]LED-32/20W / 225 mA - 2700 K1113.780
186-0386symmetric linear, medium beam [LM/IW]LED-32/20W / 225 mA - 3000 K1068.880
186-0478symmetric linear, medium beam [LM/IW]LED-32/20W / 225 mA - 2700 K1068.880
186-0388symmetric linear, narrow beam [LE/IW]LED-32/20W / 225 mA - 3000 K1113.780
186-0389symmetric linear, narrow beam [LE/IW]LED-32/20W / 225 mA - 4000 K1113.780
Showing 1 to 24 of 24 Entries
