DAC140 LED

H300

IP66, Class I. Class II on request. IK07. Marine-grade, all aluminium construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® gasket. Safety glass lens. Two cable entries. Integral EC electronic converter in thermally separated compartment. CAD-optimised optics for superior illumination and glare control. Factory installed LED circuit board. The luminaire is factory-sealed and does not need to be opened during installation.
Other standardised housing lengths, 190 mm and 250 mm available on request. Optional 2200 K version available. To be specified at time of ordering.

Eigenschaften

Material

GehäuseMarine-grade, all aluminium construction
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberStandard. Optional DALI version available. To be specified at time of ordering.
KabelTwo cable entries
Leistungsfaktor> 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
134-2246symmetric, wide beam [B]LED-24/48W / 700 mA - 2700 K4916.180EC5.50
134-2247symmetric, wide beam [B]LED-24/48W / 700 mA - 3000 K5280.380EC5.50
134-2248symmetric, wide beam [B]LED-24/48W / 700 mA - 4000 K5644.580EC5.50
134-2249symmetric, medium beam [M]LED-24/48W / 700 mA - 2700 K5378.580EC5.50
134-2250symmetric, medium beam [M]LED-24/48W / 700 mA - 3000 K5776.980EC5.50
134-2251symmetric, medium beam [M]LED-24/48W / 700 mA - 4000 K6175.380EC5.50
134-2252symmetric, very narrow beam [EE]LED-24/48W / 700 mA - 2700 K5546.880EC5.50
134-2253symmetric, very narrow beam [EE]LED-24/48W / 700 mA - 3000 K5957.780EC5.50
134-2254symmetric, very narrow beam [EE]LED-24/48W / 700 mA - 4000 K6368.680EC5.50
134-2255symmetric, very narrow beam, sharp cut-off [EES]LED-24/48W / 700 mA - 2700 K5785.280EC5.50
134-2256symmetric, very narrow beam, sharp cut-off [EES]LED-24/48W / 700 mA - 3000 K6213.780EC5.50
134-2257symmetric, very narrow beam, sharp cut-off [EES]LED-24/48W / 700 mA - 4000 K6642.280EC5.50
134-2249wallwash [A20]LED-24/48W / 700 mA - 2700 K4246.880EC5.50
134-2250wallwash [A20]LED-24/48W / 700 mA - 3000 K4561.480EC5.50
134-2251wallwash [A20]LED-24/48W / 700 mA - 4000 K4875.980EC5.50
Showing 1 to 15 of 15 Entries
