DAC110 LED

H190

Back
Standard Colours
Tunable White
Family Spec Sheet
190 mm 190 mm 105 mm 105 mm
250 mm 250 mm 140 mm 140 mm
195 mm 195 mm 300 mm 300 mm
154 mm 154 mm
250 mm 250 mm

IP66, Class I. Class II on request. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® gasket. Safety glass lens. Two cable entries. Integral EC electronic converter in thermally separated compartment. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board.
Other standardised housing lengths, 250 mm and 300 mm available on request. Optional 2200 K version available. To be specified at time of ordering.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
AbdeckungPowdercoat
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberStandard. Optional DALI version available. To be specified at time of ordering.
KabelTwo cable entries
Leistungsfaktor>0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h
Energy efficiency classC-D (Light source)

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
134-2077symmetric, wide beam [B]LED-6/12W / 700 mA - 2700 K107080EC2.00
134-2078symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1149.280EC2.00
134-2079symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K1228.580EC2.00
134-2080symmetric, medium beam [M]LED-6/12W / 700 mA - 2700 K1201.180EC2.00
134-2081symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1290.180EC2.00
134-2082symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K137980EC2.00
134-2083symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1347.780EC2.00
134-2084symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1447.680EC2.00
134-2085symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1547.480EC2.00
134-2086symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K142480EC2.00
134-2087symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1529.580EC2.00
134-2088symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K163580EC2.00
134-2080wallwash [A20]LED-6/12W / 700 mA - 2700 K817.380EC2.00
134-2081wallwash [A20]LED-6/12W / 700 mA - 3000 K877.880EC2.00
134-2082wallwash [A20]LED-6/12W / 700 mA - 4000 K938.480EC2.00
Showing 1 to 15 of 15 Entries
