RFS530 LED

Back
Family Spec Sheet
81 mm 81 mm 460 mm 460 mm
82 mm 82 mm 570 mm 570 mm

IP66, Class I. Class II on request. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Non-reflecting safety glass lens, hinged with safety switch. Integral EC electronic converter in thermally separated compartment. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. The luminaire is factory-sealed and does not need to be opened during installation. Optional 2200 K version available. To be specified at time of ordering.
Includes cable connector, for cable 6-12 mm. Cable inclination angle: Maximum 10°.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
AbdeckungPowdercoat finish in RAL9004, RAL9006, RAL9007 and RAL9016
Korrosionsschutz5CE
BefestigungIncludes cable connector, for cable 6-12 mm. Cable inclination angle: Maximum 10°.

Elektrik

LED TreiberIntegral EC electronic converter
Kabel
Leistungsfaktor< 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz6/6 kV (optional SP10)

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h
Energy efficiency classC-D (Light source)

Lichtverteilung

Lichtstrom (lm)

Leistung (W)

Farbtemperatur (K)

CRI

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
111-0697asymmetric, side throw beam [S60]LED-24/24W/24W / 700 mA - 4000 K6498.380EC11.90
111-0706asymmetric, side throw beam [S60]LED-12/6W/6W / 350 mA - 3000 K1705.880EC11.60
111-0707asymmetric, side throw beam [S60]LED-12/6W6W / 350 mA - 4000 K1870.880EC11.60
111-0708asymmetric, side throw beam [S60]LED-24/12W/12W / 350 mA - 3000 K3411.580EC11.90
111-0709asymmetric, side throw beam [S60]LED-24/12W/12W / 350 mA - 4000 K3741.780EC11.90
111-0710asymmetric, side throw beam [S65]LED-12/6W/6W / 350 mA - 3000 K1690.280EC11.60
111-0711asymmetric, side throw beam [S65]LED-12/6W6W / 350 mA - 4000 K1853.880EC11.60
111-0712asymmetric, side throw beam [S65]LED-24/12W/12W / 350 mA - 3000 K3380.480EC11.90
111-0713asymmetric, side throw beam [S65]LED-24/12W/12W / 350 mA - 4000 K3707.580EC11.90
111-0714asymmetric, side throw beam [S70]LED-12/6W/6W / 350 mA - 3000 K1616.280EC11.60
111-0715asymmetric, side throw beam [S70]LED-12/6W6W / 350 mA - 4000 K1772.680EC11.60
111-0716asymmetric, side throw beam [S70]LED-24/12W/12W / 350 mA - 3000 K3232.480EC11.90
111-0717asymmetric, side throw beam [S70]LED-24/12W/12W / 350 mA - 4000 K3545.280EC11.90
111-0718asymmetric, side throw beam [S60]LED-12/12W/12W / 700 mA - 3000 K3039.580EC11.60
111-0719asymmetric, side throw beam [S60]LED-12/12W/12W / 700 mA - 4000 K3249.280EC11.60
111-0720asymmetric, side throw beam [S60]LED-24/24W/24W / 700 mA - 3000 K6079.180EC11.90
111-0721asymmetric, side throw beam [S65]LED-12/12W/12W / 700 mA - 3000 K3011.880EC11.60
111-0722asymmetric, side throw beam [S65]LED-12/12W/12W / 700 mA - 4000 K3219.580EC11.60
111-0723asymmetric, side throw beam [S65]LED-24/24W/24W / 700 mA - 3000 K6023.680EC11.90
111-0724asymmetric, side throw beam [S65]LED-24/24W/24W / 700 mA - 4000 K643980EC11.90
111-0725asymmetric, side throw beam [S70]LED-12/12W/12W / 700 mA - 3000 K2879.980EC11.60
111-0726asymmetric, side throw beam [S70]LED-12/12W/12W / 700 mA - 4000 K3078.580EC11.60
111-0727asymmetric, side throw beam [S70]LED-24/24W/24W / 700 mA - 3000 K5759.880EC11.90
111-0728asymmetric, side throw beam [S70]LED-24/24W/24W / 700 mA - 4000 K615780EC11.90
111-1088asymmetric, side throw beam [S60]LED-12/6W/6W / 350 mA - 2700 K1595.780EC11.60
Showing 1 to 25 of 72 Entries
