STL100+STL200 series
STL134 LED Reduced Depth
IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection + primer including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry.
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware (unpainted) |
| Gasket | Silicone rubber gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Corrosion Protection | 5CE+Primer |
Electrical
| Ballast / Driver | Integral EC electronic converter |
| Cable | One cable entry |
| Power Supply | 230V / 50 Hz |
Additional Information
| Warranty | The product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details. |
- - - -
| Item | Download |
|---|---|
| Product Images | |
| Photometrics | |
| Installation Instructions | |
| WE-EF LIGHTING - TEN YEAR WARRANTY - LED LUMINAIRES |
