STI100+STI200 Série
STI134 LED Reduced Depth
Choisissez une famille :
L270×W65×D75 mm | STI134 LED Reduced Depth L250×W92×D100 mm | STI259 LED L425×W135×D100 mm | STI279 LEDIP66, Class I. IK10. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection + primer including PCS hardware. Polycarbonate main lens. Silicone rubber gasket. Luminaire is factory-sealed and does not need to be opened during installation. Factory-installed with 30 cm of flexible halogen-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. One cable entry.
Couleurs
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
Description du matériel
| Corps | Marine-grade, die-cast aluminium alloy |
| Visserie | PCS Polymer Coated Stainless Steel Hardware (unpainted) |
| Joint | Silicone rubber gasket |
| IK | IK10 |
| IP | IP66 |
| Protection contre la corrosion | 5CE+Primer |
Description électrique
| Driver | Integral EC electronic converter |
| Câble | One cable entry |
| Alimentation électrique | 230V / 50 Hz |
Informations complémentaires
| Warranty | The product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details. |
- - - -
| Item | Download |
|---|---|
| Images du produit | |
| Photométrie | |
| Instructions d'installation | |
| WE-EF LIGHTING - TEN YEAR WARRANTY - LED LUMINAIRES |
