PFL540-SE LED

IP66, Class I. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection + primer including PCS hardware. Silicone CCG® Controlled Compression Gasket. PMMA RFC® Reflection Free Contour technology. LED board can be easily removed to upgrade. CAD-optimised OLC® PMMA lens for superior illumination and glare control. DALI. Optional: Side Entry (see Mounting Accessories) A professional lighting design in consultation with the relevant sections of AS/NZS-1158.4:2015 is essential for all applications with the [P45] lens.

Colours

RAL9004 Signal black

RAL9006 White aluminium

RAL9007 Grey aluminium

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS Polymer Coated Stainless Steel Hardware (unpainted)
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK08
Ingress Protection	IP66
Finish	Powdercoat finish in black RAL9004, grey aluminium RAL9007, white aluminium RAL9006 or white RAL9016
Corrosion Protection	5CE+Primer
Mounting	Recommended mounting height 2.5-8.0 m, depending on wattage and light distribution.

Electrical

Ballast / Driver	Integral EC electronic converter. DALI
Cable	Pre-wired with 12 m cable in standard.
Power Supply	230V / 50 Hz
Surge Protection	In-pole surge protection SP10 device supplied. Please refer to WE-EF installation instructions for details. Use suffix +A for Integral surge protection.

Additional Information

Warranty

The product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details.

Light Distribution

Delivered Lumen

To

Wattage

To

Colour Temperature

CRI

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
108-8705	asymmetric, side throw [S70]	LED-24/48W / 700 mA - 3000 K	6160.9	80
108-8706	asymmetric, side throw [S70]	LED-24/48W / 700 mA - 4000 K	6585.8	80
108-8708	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 3000 K	9241.3	80
108-8709	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 4000 K	9878.6	80
108-8711	asymmetric, side throw [S70]	LED-48/96W / 700 mA - 3000 K	12321.7	80
108-8713	asymmetric, side throw [S70]	LED-48/96W / 700 mA - 4000 K	13171.5	80
108-8714	asymmetric, side throw [S60]	LED-24/48W / 700 mA - 3000 K	6268.7	80
108-8715	asymmetric, side throw [S60]	LED-24/48W / 700 mA - 4000 K	6701	80
108-8717	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 3000 K	9403.1	80
108-8718	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 4000 K	10051.6	80
108-8720	asymmetric, forward throw [A60]	LED-24/48W / 700 mA - 3000 K	5749.1	80
108-8721	asymmetric, forward throw [A60]	LED-24/48W / 700 mA - 4000 K	6145.6	80
108-8723	asymmetric, forward throw [A60]	LED-36/72W / 700 mA - 3000 K	8623.7	80
108-8724	asymmetric, forward throw [A60]	LED-36/72W / 700 mA - 4000 K	9218.5	80
108-8726	asymmetric, forward throw [A60]	LED-48/96W / 700 mA - 3000 K	11498.3	80
108-8727	asymmetric, forward throw [A60]	LED-48/96W / 700 mA - 4000 K	12291.3	80
108-8729	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 3000 K	9491	80
108-8730	asymmetric, side throw [S60]	LED-48/96W / 700 mA - 3000 K	12537.4	80
108-8733	asymmetric, side throw [S60]	LED-48/96W / 700 mA - 4000 K	13402.1	80
108-8734	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 4000 K	10145.6	80
108-8735	asymmetric, side throw [S65]	LED-24/48W / 700 mA - 3000 K	6327.3	80
108-8736	asymmetric, side throw [S65]	LED-24/48W / 700 mA - 4000 K	6763.7	80
108-8738	asymmetric, side throw [S65]	LED-48/96W / 700 mA - 3000 K	12654.7	80
108-8739	asymmetric, side throw [S65]	LED-48/96W / 700 mA - 4000 K	13527.4	80
108-8741	rectangular, side throw [R65]	LED-24/48W / 700 mA - 3000 K	5889.5	80
108-8742	rectangular, side throw [R65]	LED-24/48W / 700 mA - 4000 K	6295.7	80
108-8744	rectangular, side throw [R65]	LED-36/72W / 700 mA - 3000 K	8834.2	80
108-8745	rectangular, side throw [R65]	LED-36/72W / 700 mA - 4000 K	9443.5	80
108-5339	pedestrian crossing, left-hand traffic [P45L]	LED-48/96W / 700 mA - 3000 K	12170.5	80
108-8761	rectangular, side throw [R65]	LED-48/96W / 700 mA - 4000 K	12591.3	80
108-8766	asymmetric, side throw [S65]	LED-24/72W / 1050 mA - 3000 K	9380.3	80
108-8767	asymmetric, side throw [S65]	LED-24/72W / 1050 mA - 4000 K	9816.6	80
108-8770	asymmetric, side throw [S70]	LED-24/72W / 1050 mA - 3000 K	9056.9	80
108-8771	asymmetric, side throw [S70]	LED-24/72W / 1050 mA - 4000 K	9478.2	80
108-8773	asymmetric, side throw [S70]	LED-36/108W / 1050 mA - 3000 K	13585.4	80
108-8774	asymmetric, side throw [S70]	LED-36/108W / 1050 mA - 4000 K	14217.3	80
108-8776	asymmetric, side throw [S70]	LED-48/144W / 1050 mA - 3000 K	18113.9	80
108-8777	asymmetric, side throw [S70]	LED-48/144W / 1050 mA - 4000 K	18956.4	80
108-8779	asymmetric, side throw [S60]	LED-24/72W / 1050 mA - 3000 K	9200.3	80
108-8780	asymmetric, side throw [S60]	LED-24/72W / 1050 mA - 4000 K	9628.2	80
108-8782	asymmetric, side throw [S60]	LED-36/108W / 1050 mA - 3000 K	13800.4	80
108-8783	asymmetric, side throw [S60]	LED-36/108W / 1050 mA - 4000 K	14442.3	80
108-8785	asymmetric, side throw [S60]	LED-48/144W / 1050 mA - 3000 K	18400.5	80
108-8786	asymmetric, side throw [S60]	LED-48/144W / 1050 mA - 4000 K	19256.4	80
108-8788	asymmetric, forward throw [A60]	LED-24/72W / 1050 mA - 3000 K	8506.1	80
108-8789	asymmetric, forward throw [A60]	LED-24/72W / 1050 mA - 4000 K	8901.8	80
108-8791	asymmetric, forward throw [A60]	LED-36/108W / 1050 mA - 3000 K	12759.2	80
108-8792	asymmetric, forward throw [A60]	LED-36/108W / 1050 mA - 4000 K	13352.6	80
108-8794	asymmetric, forward throw [A60]	LED-48/144W / 1050 mA - 3000 K	17012.3	80
108-8795	asymmetric, forward throw [A60]	LED-48/144W / 1050 mA - 4000 K	17803.5	80

Showing 1 to 50 of 131 entries.

Accessories

Control

Mounting Accessories

Optical Accessories

Part-ID	Title	Specifications
		Text	PDF
430-0001	Eco Step Dim® Basic LED

Item	Download
Product Images
Photometrics
Installation Instructions
WE-EF LIGHTING - TEN YEAR WARRANTY - LED LUMINAIRES
WE-EF Revit Files - PFL540-SE LED
WE-EF ADSA Certified
WE-EF Technical Information - In-Pole SPD Installation Instructions
