FLC200-ZHAGA series
FLC230 Zhaga
IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland. Second gland for through wiring on request. Integral EC electronic converter, thermally separated. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory installed LED circuit board. 1-10V, DALI Interface or Eco Step Dim® on request. Maximum one internal optical accessory possible. Optional 2200 K version up to max. 1050mA available. To be specified at time of ordering.
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9007 Grey aluminium
Material
| Body | Marine-grade, die-cast aluminium alloy |
| Fasteners | PCS Polymer Coated Stainless Steel Hardware (unpainted) |
| Gasket | Silicone CCG® Controlled Compression Gasket |
| Impact Protection | IK07 |
| Ingress Protection | IP66 |
| Corrosion Protection | 5CE+Primer |
Electrical
| Ballast / Driver | Integral EC electronic convertor in thermally-separated compartment. DALI |
| Cable | One cable entry, second cable entry on request |
| Power Factor | > 0.9 |
| Power Supply | 220-240V / 50-60 Hz |
| Surge Protection | 6/6 kV (optional SP10) |
Additional Information
- - - -
| Item | Download |
|---|
