BUC200 Série

BUC230 LED

Static White

Choisissez une famille :

BUC230 LED
L×W: 320×210 mm
Accueil
Produits
Ceiling Luminaires
BUC230 LED
Fiche technique de la famille Instructions d'installation Autres téléchargements

IP66. IK10. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection + primer including PCS hardware. PMMA lens. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Integrated side and rear cable entries for installation flexibility. Optional 1-10 V analogue dimming interface.

BUC230 LED Schematics
Couleurs
RAL9004 Signal black
Description du matériel
CorpsMarine-grade, die-cast aluminium alloy
VisseriePCS Polymer Coated Stainless Steel Hardware (unpainted)
JointSilicone CCG® Controlled Compression Gasket
IKIK10
IPIP66
Protection contre la corrosion5CE+Primer
Description électrique
DriverIntegral EC electronic converter
Alimentation électrique230V / 50 Hz
Informations complémentaires
LifetimeLED>60,000 h Ta 25° (L70/B10) Control gear >50,000 h Ta 25°
WarrantyThe product is supplied with 10-year warranty. Please refer to the LED Warranty Statement located on www.we-ef.com for further details.

Données en sortie de luminaire

To

Puissance

To
Code produitDistribution photométriqueSource lumineuseDonnées en sortie de luminaireIRCCaractéristiquesPhotométrie
TextePDF
195-8500asymmetric, side throw [S60]LED-6/12W / 700 mA - 4000 K1615.680 ULD
195-8501asymmetric, side throw [S60]LED-6/12W / 700 mA - 3000 K1511.380 ULD
195-8502asymmetric, side throw [S60]LED-12/24W / 700 mA - 4000 K3231.180 ULD
195-8503asymmetric, side throw [S60]LED-12/24W / 700 mA - 3000 K3022.780 ULD
195-8504asymmetric, side throw [S60]LED-18/36W / 700 mA - 4000 K4846.780 ULD
195-8505asymmetric, side throw [S60]LED-18/36W / 700 mA - 3000 K453480 ULD
195-8506asymmetric, side throw [S70]LED-6/12W / 700 mA - 4000 K153480 ULD
195-8507asymmetric, side throw [S70]LED-6/12W / 700 mA - 3000 K143580 ULD
195-8508asymmetric, side throw [S70]LED-12/24W / 700 mA - 4000 K3067.980 ULD
195-8509asymmetric, side throw [S70]LED-12/24W / 700 mA - 3000 K287080 ULD
195-8510asymmetric, side throw [S70]LED-18/36W / 700 mA - 4000 K4601.980 ULD
195-8511asymmetric, side throw [S70]LED-18/36W / 700 mA - 3000 K430580 ULD
195-8512asymmetric, forward throw [A60]LED-6/12W / 700 mA - 4000 K1528.180 ULD
195-8513asymmetric, forward throw [A60]LED-6/12W / 700 mA - 3000 K1429.580 ULD
195-8514asymmetric, forward throw [A60]LED-12/24W / 700 mA - 4000 K3056.280 ULD
195-8515asymmetric, forward throw [A60]LED-12/24W / 700 mA - 3000 K2859.180 ULD
195-8516asymmetric, forward throw [A60]LED-18/36W / 700 mA - 4000 K4584.480 ULD
195-8517asymmetric, forward throw [A60]LED-18/36W / 700 mA - 3000 K4288.680 ULD
195-8518asymmetric, side throw [S65]LED-6/12W / 700 mA - 4000 K1640.580 ULD
195-8519asymmetric, side throw [S65]LED-6/12W / 700 mA - 3000 K1534.780 ULD
195-8520asymmetric, side throw [S65]LED-12/24W / 700 mA - 4000 K328180 ULD
195-8521asymmetric, side throw [S65]LED-12/24W / 700 mA - 3000 K3069.380 ULD
195-8522asymmetric, side throw [S65]LED-18/36W / 700 mA - 4000 K4921.580 ULD
195-8523asymmetric, side throw [S65]LED-18/36W / 700 mA - 3000 K460480 ULD
195-8524rectangular, side throw [R65]LED-6/12W / 700 mA - 4000 K1451.880 ULD
195-8525rectangular, side throw [R65]LED-6/12W / 700 mA - 3000 K1358.180 ULD
195-8526rectangular, side throw [R65]LED-12/24W / 700 mA - 4000 K2903.580 ULD
195-8527rectangular, side throw [R65]LED-12/24W / 700 mA - 3000 K2716.280 ULD
195-8528rectangular, side throw [R65]LED-18/36W / 700 mA - 4000 K4355.380 ULD
195-8529rectangular, side throw [R65]LED-18/36W / 700 mA - 3000 K4074.380 ULD
195-8530bi-symmetric, wide beam [B65]LED-6/12W / 700 mA - 4000 K1562.480 ULD
195-8531bi-symmetric, wide beam [B65]LED-6/12W / 700 mA - 3000 K1461.680 ULD
195-8532bi-symmetric, wide beam [B65]LED-12/24W / 700 mA - 4000 K3124.880 ULD
195-8533bi-symmetric, wide beam [B65]LED-12/24W / 700 mA - 3000 K2923.280 ULD
195-8534square distribution [Q]LED-18/36W / 700 mA - 4000 K4714.280 ULD
195-8535square distribution [Q]LED-18/36W / 700 mA - 3000 K4410.180 ULD
195-8537bi-symmetric, wide beam [B65]LED-18/36W / 700 mA - 4000 K4687.180 ULD
195-8538bi-symmetric, wide beam [B65]LED-18/36W / 700 mA - 3000 K4384.780 ULD
