FLC100 series

FLC122 LED

Static White

Choose a family:

⌀111 mm | FLC122 LED ⌀190 mm | FLC142 LED
Home
Products
Surface-Mounted Wall Luminaires
FLC122 LED
Family Spec Sheet Installation Instructions More Downloads

IP55. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept.

FLC122 LED Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP55
FinishPowdercoat finish in RAL9004, RAL9006, RAL9007, RAL7016 and RAL9016
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Additional Information

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
145-9374symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1511.880
145-9375symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1496.580
145-9377symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1616.180
145-9378symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1599.780
145-9382symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1610.780
145-9383symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1347.180
145-9384symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1721.880
145-9385symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K144080
Showing 1 to 8 of 8 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
145-0030Snoot ET
ItemDownload
