FLC100 series

FLC142 LED

Static White

Choose a family:

⌀111 mm | FLC122 LED ⌀190 mm | FLC142 LED
Home
Products
Surface-Mounted Wall Luminaires
FLC142 LED
Family Spec Sheet Installation Instructions More Downloads

IP55. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept.

FLC142 LED Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP55
FinishPowdercoat finish in RAL9004, RAL9006, RAL9007, RAL7016 and RAL9016
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Additional Information

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
146-9959symmetric, wide beam [B]LED-24/48W / 700 mA - 3000 K5388.580
146-9964symmetric, wide beam [B]LED-24/48W / 700 mA - 4000 K5760.180
146-9958symmetric, medium beam [M]LED-24/48W / 700 mA - 3000 K6047.280
146-9963symmetric, medium beam [M]LED-24/48W / 700 mA - 4000 K6464.280
146-9957symmetric, very narrow beam [EE]LED-24/48W / 700 mA - 3000 K5986.180
146-9962symmetric, very narrow beam [EE]LED-24/48W / 700 mA - 4000 K6398.980
146-9956symmetric, very narrow beam, sharp cut-off [EES]LED-24/48W / 700 mA - 3000 K6442.780
146-9961symmetric, very narrow beam, sharp cut-off [EES]LED-24/48W / 700 mA - 4000 K688780
Showing 1 to 8 of 8 entries.
