FLD100 series

FLD131 LED Spigot mounted

Static White

Choose a variant:

Spigot
Surface
Wallbracket

Choose a family:

FLD111 LED Spigot mounted
L×W: 95×95 mm
FLD121 LED Spigot mounted
L×W: 175×130 mm
FLD131 LED Spigot mounted
L×W: 200×156 mm
Home
Products
Projectors
FLD131 LED Spigot mounted
Family Spec Sheet Installation Instructions More Downloads

IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-shielded compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Including 1.5 m of flexible PVC free cable and IP68 in-line connector. Mounting accessories to be ordered separately.

FLD131 LED Spigot mounted Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
FinishPowdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection5CE
MountingSlipfitter suitable for mounting accessories
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-shielded compartment
CableIncluding 1.5 m of flexible PVC free cable and IP68 in-line connector
Additional Information

Rated Lumen

Wattage

To
Part-IDLight DistributionLight SourceRated LumenCRISpecificationsPhotometrics
TextPDF
145-9542symmetric, medium beam [M]LED-12/24W / 700 mA - 3000 K2908.180 ULD
145-9543symmetric, very narrow beam [EE]LED-12/24W / 700 mA - 3000 K2786.980 ULD
145-9545symmetric, medium beam [M]LED-12/24W / 700 mA - 4000 K3108.780 ULD
145-9546symmetric, very narrow beam [EE]LED-12/24W / 700 mA - 4000 K2979.180 ULD
145-9600symmetric, wide beam [B]LED-12/24W / 700 mA - 3000 K2296.780 ULD
145-9601symmetric, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 3000 K2985.880 ULD
145-9602symmetric, wide beam [B]LED-12/24W / 700 mA - 4000 K245580 ULD
145-9603symmetric, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 4000 K3191.880 ULD
145-9545wallwashLED-12/24W / 700 mA - 4000 K2442.480 ULD
145-9542wallwashLED-12/24W / 700 mA - 3000 K2284.980 ULD
145-9894symmetric, wide beam [B]LED-12/36W / 1050 mA - 3000 K3795.180 ULD
145-9895symmetric, wide beam [B]LED-12/36W / 1050 mA - 4000 K3971.680 ULD
145-9890symmetric, medium beam [M]LED-12/36W / 1050 mA - 3000 K4325.280 ULD
145-9891symmetric, medium beam [M]LED-12/36W / 1050 mA - 4000 K4526.480 ULD
145-9892symmetric, very narrow beam [EE]LED-12/36W / 1050 mA - 3000 K4093.280 ULD
145-9893symmetric, very narrow beam [EE]LED-12/36W / 1050 mA - 4000 K4283.680 ULD
145-9634symmetric, wide beam [B]LED-12/24W / 700 mA - 2700 K2138.380 ULD
145-9635symmetric, medium beam [M]LED-12/24W / 700 mA - 2700 K2715.880 ULD
145-9636symmetric, very narrow beam [EE]LED-12/24W / 700 mA - 2700 K2239.180
145-9637symmetric, very narrow beam, sharp cut-off [EES]LED-12/24W / 700 mA - 2700 K2779.980 ULD
Showing 1 to 20 of 20 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
430-00111-10 V analogue dimming interface
