IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-shielded compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Including 1.5 m of flexible PVC free cable and IP68 in-line connector. Mounting accessories to be ordered separately.

FLD121 LED #1 Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
FinishPowdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Corrosion Protection5CE
MountingSlipfitter suitable for mounting accessories
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-shielded compartment
CableIncluding 1.5 m of flexible PVC free cable and IP68 in-line connector
Additional Information

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
145-9491symmetric, medium beam [M]LED-6/12W / 700 mA - 3000 K1454.180
145-9492symmetric, medium beam [M]LED-6/12W / 700 mA - 4000 K1554.380
145-9493symmetric, wide beam [B]LED-6/12W / 700 mA - 3000 K1148.380
145-9494symmetric, wide beam [B]LED-6/12W / 700 mA - 4000 K1227.580
145-9495symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 3000 K1393.480
145-9496symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 4000 K1489.580
145-9497symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 3000 K1492.980
145-9498symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 4000 K1595.980
145-9492wallwashLED-6/12W / 700 mA - 4000 K1221.280
145-9491wallwashLED-6/12W / 700 mA - 3000 K1142.480
145-9852symmetric, wide beam [B]LED-6/18W / 1050 mA - 3000 K2018.880
145-9853symmetric, wide beam [B]LED-6/18W / 1050 mA - 4000 K2112.780
145-9850symmetric, medium beam [M]LED-6/18W / 1050 mA - 3000 K2167.280
145-9851symmetric, medium beam [M]LED-6/18W / 1050 mA - 4000 K226880
145-9854symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 3000 K2165.680
145-9855symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 4000 K2266.480
145-7133symmetric, wide beam [B]LED-6/12W / 700 mA - 2700 K1069.180
145-7153symmetric, wide beam [B]LED-6/18W / 1050 mA - 2700 K1924.980
145-7132symmetric, medium beam [M]LED-6/12W / 700 mA - 2700 K1353.880
145-7152symmetric, medium beam [M]LED-6/18W / 1050 mA - 2700 K2066.480
145-7134symmetric, very narrow beam [EE]LED-6/12W / 700 mA - 2700 K1297.380
145-7154symmetric, very narrow beam [EE]LED-6/18W / 1050 mA - 2700 K2064.980
145-7135symmetric, very narrow beam, sharp cut-off [EES]LED-6/12W / 700 mA - 2700 K139080
Showing 1 to 23 of 23 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
145-9479Wallwash lens IO-20
