FLD100 Série

FLD111 LED Spigot mounted

Static White

Choisissez une variante :

Spigot-Mounted
Surface-Mounted
Wallbracket

Choisissez une famille :

FLD111 LED Spigot mounted
L×W: 95×95 mm
FLD121 LED Spigot mounted
L×W: 175×130 mm
FLD131 LED Spigot mounted
L×W: 200×156 mm
Accueil
Produits
Projectors
FLD111 LED #1
Fiche technique de la famille Instructions d'installation Autres téléchargements

IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Remote EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Including 1.5 m of flexible PVC free cable and IP68 in-line connector. Mounting accessories to be ordered separately.

FLD111 LED #1 Schematics
Couleurs
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Description du matériel
CorpsMarine-grade, die-cast aluminium alloy
VisseriePCS hardware
JointSilicone CCG® Controlled Compression Gasket
IKIK07
IPIP66
FinitionPowdercoat finish in black RAL 9004, grey aluminium RAL 9007 or white RAL 9016
Protection contre la corrosion5CE
MontageSlipfitter suitable for mounting accessories
Description électrique
DriverRemote EC electronic converter
CâbleIncluding 1.5 m of flexible PVC free cable and IP68 in-line connector
Informations complémentaires

Données en sortie de luminaire

To

Puissance

To
Code produitDistribution photométriqueSource lumineuseDonnées en sortie de luminaireIRCCaractéristiquesPhotométrie
TextePDF
145-9782symmetric, medium beam [M]LED-3/6W / 700 mA - 3000 K696.380 ULD
145-9783symmetric, very narrow beam [EE]LED-3/6W / 700 mA - 3000 K650.780 ULD
145-9784symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 3000 K1721.880 ULD
145-9786symmetric, medium beam [M]LED-3/6W / 700 mA - 4000 K744.380 ULD
145-9787symmetric, very narrow beam [EE]LED-3/6W / 700 mA - 4000 K695.680 ULD
145-9788symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 4000 K74980 ULD
145-9782wallwashLED-3/6W / 700 mA - 3000 K458.280 ULD
145-9786wallwashLED-3/6W / 700 mA - 4000 K489.780 ULD
145-7080symmetric, wide beam [B]LED-3/6W / 700 mA - 3000 K584.980 ULD
145-7081symmetric, wide beam [B]LED-3/6W / 700 mA - 4000 K625.380 ULD
145-7000symmetric, wide beam [B]LED-3/9W / 1050mA - 3000 K841.580 ULD
145-7001symmetric, wide beam [B]LED-3/9W / 1050mA - 4000 K880.680 ULD
145-7002symmetric, medium beam [M]LED-3/9W / 1050mA - 3000 K965.480 ULD
145-7003symmetric, medium beam [M]LED-3/9W / 1050mA - 4000 K1010.380 ULD
145-7004symmetric, very narrow beam [EE]LED-3/9W / 1050mA - 3000 K1058.880 ULD
145-7005symmetric, very narrow beam [EE]LED-3/9W / 1050mA - 4000 K110880 ULD
145-7100symmetric, wide beam [B]LED-3/6W / 700 mA - 2700 K544.680 ULD
145-7101symmetric, medium beam [M]LED-3/6W / 700 mA - 2700 K648.380 ULD
145-7102symmetric, very narrow beam [EE]LED-3/6W / 700 mA - 2700 K605.880 ULD
145-7103symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 2700 K652.380 ULD
145-7120symmetric, wide beam [B]LED-3/9W / 1050 mA - 2700 K802.380 ULD
145-7121symmetric, medium beam [M]LED-3/9W / 1050 mA - 2700 K920.580 ULD
145-7122symmetric, very narrow beam [EE]LED-3/9W / 1050 mA - 2700 K1009.580 ULD
Affichage de 1 à 23 sur 23 résultats

Accessories

Code produitTitreCaractéristiques
TextePDF
145-9535Flat surface fitter FLD100
145-9536Column fitter FLD100
