FLC210 LED

Back
Standard Colours
Tunable White
Family Spec Sheet
Standard Projector Standard Projector 75 mm 75 mm
Standard Projector Standard Projector 150 mm 150 mm
Standard Projector Standard Projector 190 mm 190 mm
Standard Projector Standard Projector 260 mm 260 mm
Standard Projector Standard Projector 340 mm 340 mm
Standard Projector Standard Projector 385 mm 385 mm

IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket.
Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter in thermally-separated compartment
Kabel
Leistungsfaktor
Netz
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
139-2361symmetric, wide beam [B]LED-3/6W / 180 mA - 2700 K643.380EC2.00
139-2359symmetric, wide beam [B]LED-3/6W / 180 mA - 3000 K643.380EC2.00
139-2360symmetric, wide beam [B]LED-3/6W / 180 mA - 4000 K692.880EC2.00
139-2364symmetric, medium beam [M]LED-3/6W / 180 mA - 2700 K684.180EC2.00
139-2362symmetric, medium beam [M]LED-3/6W / 180 mA - 3000 K684.180EC2.00
139-2363symmetric, medium beam [M]LED-3/6W / 180 mA - 4000 K736.880EC2.00
139-2367symmetric, narrow beam [E]LED-3/6W / 180 mA - 2700 K629.980EC2.00
139-2365symmetric, narrow beam [E]LED-3/6W / 180 mA - 3000 K629.980EC2.00
139-2366symmetric, narrow beam [E]LED-3/6W / 180 mA - 4000 K678.380EC2.00
139-2370symmetric, very narrow beam [EE]LED-3/6W / 180 mA - 2700 K693.280EC2.00
139-2368symmetric, very narrow beam [EE]LED-3/6W / 180 mA - 3000 K693.280EC2.00
139-2369symmetric, very narrow beam [EE]LED-3/6W / 180 mA - 4000 K746.580EC2.00
139-2373symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 180 mA - 2700 K624.880EC2.00
139-2371symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 180 mA - 3000 K624.880EC2.00
139-2372symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 180 mA - 4000 K676.880EC2.00
139-2376symmetric, wide beam [B]LED-3/9W / 250 mA - 2700 K903.180EC2.00
139-2374symmetric, wide beam [B]LED-3/9W / 250 mA - 3000 K903.180EC2.00
139-2375symmetric, wide beam [B]LED-3/9W / 250 mA - 4000 K96580EC2.00
139-2379symmetric, medium beam [M]LED-3/9W / 250 mA - 2700 K960.480EC2.00
139-2377symmetric, medium beam [M]LED-3/9W / 250 mA - 3000 K960.480EC2.00
139-2378symmetric, medium beam [M]LED-3/9W / 250 mA - 4000 K1026.280EC2.00
139-2382symmetric, narrow beam [E]LED-3/9W / 250 mA - 2700 K884.280EC2.00
139-2380symmetric, narrow beam [E]LED-3/9W / 250 mA - 3000 K884.280EC2.00
139-2381symmetric, narrow beam [E]LED-3/9W / 250 mA - 4000 K944.880EC2.00
139-2385symmetric, very narrow beam [EE]LED-3/9W / 250 mA - 2700 K973.180EC2.00
Showing 1 to 25 of 62 Entries
