LTM400

IP55, Class I. IK09. Marine-grade, all-aluminium construction. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Polycarbonate lens. Integral EC electronic converter. CAD-optimised optics for superior illumination and glare control. Optional 2200 K version available. To be specified at time of ordering. Service door with fused cable connecting box. Supplied as a complete luminaire (luminaire head and standpipe). Please note: The standpipe height must be entered for the photometric calculation.

Colors

RAL9004 Signal black

RAL9006 White aluminium

RAL9007 Grey aluminium

RAL7016 Anthracite grey

RAL9016 Traffic white

RAL8019 Grey brown

Powdercoat finish available in 35 different colours

Material

Body	Marine-grade, all-aluminium construction
Fasteners	PCS Polymer Coated Stainless Steel Hardware
Gasket	Silicone rubber gasket
Impact Protection	IK09
Ingress Protection	IP55
Finish
Corrosion Protection	5CE
Mounting

Electrical

Ballast / Driver	Integral EC electronic converter
Cable
Power Factor	> 0.9
Power Supply
Surge Protection

Additional Information

Lifetime	Ta=25° L90B10 > 90000h

Light Distribution

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
115-1525	asymmetric, side throw [S65]	LED-9/18W / 700 mA - 3000 K	2320.1	80
115-1526	asymmetric, side throw [S65]	LED-9/18W / 700 mA - 4000 K	2480.1	80
115-1527	rectangular, side throw [R65]	LED-9/18W / 700 mA - 3000 K	2448.9	80
115-1528	rectangular, side throw [R65]	LED-9/18W / 700 mA - 4000 K	2617.8	80
115-1569	asymmetric, side throw [S65]	LED-9/27W / 1050 mA - 3000 K	3440.2	80
115-1570	asymmetric, side throw [S65]	LED-9/27W / 1050 mA - 4000 K	3600.2	80
115-1567	rectangular, side throw [R65]	LED-9/27W / 1050 mA - 3000 K	3631.1	80
115-1568	rectangular, side throw [R65]	LED-9/27W / 1050 mA - 4000 K	3800	80
115-1782	asymmetric, side throw [S65]	LED-9/18W / 700 mA - 2700 K	2160.1	80
115-1783	asymmetric, side throw [S65]	LED-9/27W / 1050 mA - 2700 K	3280.1	80
115-1784	rectangular, side throw [R65]	LED-9/18W / 700 mA - 2700 K	2280	80
115-1785	rectangular, side throw [R65]	LED-9/27W / 1050 mA - 2700 K	3462.2	80

Showing 1 to 12 of 12 Entries
