LTM440 LED

LTM440 LED

Family Spec Sheet

IP66. Class I. IK09. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate outer lens. Service door with fused cable connecting box. CAD-optimized optics for superior illumination and glare control. 0-10V Dimming comes standard with luminaire. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

LTM440 LED Schematics
Colors
Material

Body: Luminaire head, base plate and base plate cover constructed in die cast aluminum

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK09

Ingress Protection: IP66

Finish:

Corrosion Protection: 5CE

Mounting: Light column suitable for installation in landscaped areas on concrete foundations, or in landscaped areas using optional planted root, 697-9307

Electrical

Ballast / Driver: Integral EC electronic converter

Cable:

Power Factor: > 0.9

Power Supply: Integral [ECG] LED driver in 120-277V

Surge Protection: In-line bracket 10kV Surge Protector

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

:

:

Light Distribution

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
115-1525[S65] Type III MediumLED-9/18W / 700 mA - 3000 K2320.180
115-1526[S65] Type III MediumLED-9/18W / 700 mA - 4000 K2480.180
115-1527[R65] Type IV MediumLED-9/18W / 700 mA - 3000 K2448.980
115-1528[R65] Type IV MediumLED-9/18W / 700 mA - 4000 K2617.880
115-1569[S65] Type III MediumLED-9/27W / 1050 mA - 3000 K3440.280
115-1570[S65] Type III MediumLED-9/27W / 1050 mA - 4000 K3600.280
115-1567[R65] Type IV MediumLED-9/27W / 1050 mA - 3000 K3631.180
115-1568[R65] Type IV MediumLED-9/27W / 1050 mA - 4000 K380080
115-1782[S65] Type III MediumLED-9/18W / 700 mA - 2700 K2160.180
115-1783[S65] Type III MediumLED-9/27W / 1050 mA - 2700 K3280.180
115-1784[R65] Type IV MediumLED-9/18W / 700 mA - 2700 K228080
115-1785[R65] Type IV MediumLED-9/27W / 1050 mA - 2700 K3462.280
Showing 1 to 12 of 12 Entries
