LTM400 series

LTM440 LED-FT

Static White

Choose a family:

LTM440 LED
H: 4000 mm
LTM440 LED-FT
H: 4000 mm
Home
Products
Light Columns
LTM440 LED-FT
Family Spec Sheet Installation Instructions More Downloads

IP55, Class I. IK09. Marine-grade, all-aluminium construction. 5CE superior corrosion protection including PCS hardware. Silicone rubber gaskets. Polycarbonate lens. Integral EC electronic converter. CAD-optimised lens for superior illumination and glare control. Service door with fused cable connecting box.

LTM440 LED-FT Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, all-aluminium construction
FastenersPCS hardware
GasketSilicone rubber gasket
Impact ProtectionIK09
Ingress ProtectionIP55
FinishPowdercoat finish in RAL9004, RAL9006, RAL9007, RAL7016 and RAL9016
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
CableService door with fused cable connecting box
Additional Information
LifetimeTa=25° L70B50 > 90000h

Rated Lumen

Wattage

To
Part-IDLight DistributionLight SourceRated LumenCRISpecificationsPhotometrics
TextPDF
115-9446symmetric distribution [C60]LED-FT-17W / 500 mA - 3000 K2071.280 ULD
115-9447symmetric distribution [C60]LED-FT-17W / 500 mA - 4000 K2158.980 ULD
115-9448symmetric distribution [C60]LED-FT-24W / 700 mA - 3000 K284780 ULD
115-9449symmetric distribution [C60]LED-FT-24W / 700 mA - 4000 K2968.480 ULD
115-1521controlled symmetric distribution [C50]LED-FT-17W / 500 mA - 3000 K2508.180 ULD
115-1522controlled symmetric distribution [C50]LED-FT-17W / 500 mA - 4000 K2614.380 ULD
115-1523controlled symmetric distribution [C50]LED-FT-24W / 700 mA - 3000 K3447.680 ULD
115-1524controlled symmetric distribution [C50]LED-FT-24W / 700 mA - 4000 K3594.680 ULD
115-1778controlled symmetric distribution [C50]LED-FT-17W / 500 mA - 2700 K2397.880 ULD
115-1779controlled symmetric distribution [C50]LED-FT-24W / 700 mA - 2700 K3308.780 ULD
115-9453symmetric distribution [C60]LED-FT-17W / 500 mA - 2700 K1980.180 ULD
115-9454symmetric distribution [C60]LED-FT-24W / 700 mA - 2700 K2732.380 ULD
115-1846rectangular [R50]LED-FT-17W / 500 mA - 2700 K2297.680 ULD
115-1840rectangular [R50]LED-FT-17W / 500 mA - 3000 K2403.380 ULD
115-1845rectangular [R50]LED-FT-17W / 500 mA - 4000 K2505.180 ULD
115-1849rectangular [R50]LED-FT-24W / 700 mA - 2700 K3170.580 ULD
115-1847rectangular [R50]LED-FT-24W / 700 mA - 3000 K3303.680 ULD
115-1848rectangular [R50]LED-FT-24W / 700 mA - 4000 K3444.580 ULD
115-1852rectangular [R50]LED-FT-37W / 700 mA - 2700 K4810.580 ULD
115-1850rectangular [R50]LED-FT-37W / 700 mA - 3000 K4955.480 ULD
115-1851rectangular [R50]LED-FT-37W / 700 mA - 4000 K5241.180 ULD
Showing 1 to 21 of 21 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
159-0321Light shield LS180
