EVC300 Série

EVC310-FS LED

Static White
Colour Changer
Tunable White

Choisissez une famille :

D154 ⌀127 mm | EVC310-FS LED D154 ⌀127 mm | EVC319-FS LED D175 ⌀172 mm | EVC320-FS LED D175 ⌀172 mm | EVC329-FS LED D195 ⌀272 mm | EVC330-FS LED D195 ⌀272 mm | EVC339-FS LED D195 ⌀322 mm | EVC340-FS LED
Accueil
Produits
Inground Luminaires
EVC310-FS LED
Fiche technique de la famille Instructions d'installation Autres téléchargements

IP68. IK10+. Stainless steel construction including PCS hardware. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Anti-wick technology, equipped with a cable gland and 0.5 meters of flexible, PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Luminaire installation blockout and sealable junction box included in supply.

EVC310-FS LED Schematics
Couleurs
Stainless Steel
Description du matériel
CorpsStainless steel construction
VisseriePCS hardware
JointSilicone rubber gasket
IKIK10+
IPIP68
Finition-
MontageLuminaire installation blockout and sealable junction box included in supply
Description électrique
DriverIntegral EC electronic converter
CâbleComplete with cable gland and 0.5 m of flexible PVC-free cable
Informations complémentaires

Données en sortie de luminaire

To
Code produitDistribution photométriqueSource lumineuseDonnées en sortie de luminaireIRCCaractéristiquesPhotométrie
TextePDF
185-9935symmetric, medium beam [M]LED-3/6W / 700 mA - 3000 K696.380
185-9936symmetric, very narrow beam [EE]LED-3/6W / 700 mA - 3000 K650.780
185-9937symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 3000 K700.780
185-9938symmetric, medium beam [M]LED-3/6W / 700 mA - 4000 K744.380
185-9939symmetric, very narrow beam [EE]LED-3/6W / 700 mA - 4000 K695.680
185-9940symmetric, very narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 4000 K74980
185-9935wallwashLED-3/6W / 700 mA - 3000 K458.280
185-9938wallwashLED-3/6W / 700 mA - 4000 K489.780
185-9939flood, very narrow beam [EE]LED-3/6W / 700 mA - 4000 K647.180
185-9939linear spread, very narrow beam [EE]LED-3/6W / 700 mA - 4000 K673.580
185-9940flood, narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 4000 K701.580
185-9940linear spread, very narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 4000 K706.980
185-9936linear spread, very narrow beam [EE]LED-3/6W / 700 mA - 3000 K63080
185-9936flood, very narrow beam [EE]LED-3/6W / 700 mA - 3000 K605.380
185-9937linear spread, very narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 3000 K661.380
185-9937flood, narrow beam, sharp cut-off [EES]LED-3/6W / 700 mA - 3000 K656.380
Affichage de 1 à 16 sur 16 résultats

Accessories

Code produitTitreCaractéristiques
TextePDF
430-00111-10 V analogue dimming interface
ItemDownload
Images du produit
Photométrie
Instructions d'installation
Manuel
WE-EF Revit Files - EVC310-FS LED
