ETC300 series

ETC330-GB LED

Static White Colour Changer Tunable White

Choose a variant:

Fixed

Gimbal

Choose a family:

D180 ⌀160 mm | ETC320-GB LED D200 ⌀250 mm | ETC330-GB LED D200 ⌀300 mm | ETC340-GB LED

Family Spec Sheet Installation Instructions More Downloads

IP69. IK10+. Stainless steel construction including PCS hardware. Safety glass lens, max. load 5 tonnes. Luminaire can be driven over at low speed. Silicone rubber gasket. Anti-wick technology, equipped with a cable gland and 0.5 meters of flexible, PVC-free cable. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. 20° tiltable and 355° rotatable. 1-10 V analogue dimming or DALI interface available on request. Luminaire installation blockout and sealable junction box included in supply.

Colours

Stainless Steel

Material

Body	Stainless steel construction
Fasteners	PCS hardware
Gasket	Silicone rubber gasket
Impact Protection	IK10+
Ingress Protection	IP69
Finish	-
Mounting	Luminaire installation blockout and sealable junction box included in supply

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	Complete with cable gland and 0.5 m of flexible PVC-free cable

Additional Information

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
185-7227	symmetric, very narrow beam, sharp cut-off [EES]	LED-6/12W / 700 mA - 3000 K	1624.7	80
185-7229	symmetric, very narrow beam, sharp cut-off [EES]	LED-6/12W / 700 mA - 4000 K	1736.8	80
185-7232	symmetric, very narrow beam [EE]	LED-6/12W / 700 mA - 3000 K	1497	80
185-7233	symmetric, medium beam [M]	LED-6/12W / 700 mA - 3000 K	1531.8	80
185-7235	symmetric, very narrow beam [EE]	LED-6/12W / 700 mA - 4000 K	1600.3	80
185-7236	symmetric, medium beam [M]	LED-6/12W / 700 mA - 4000 K	1637.4	80
185-9672	symmetric, wide beam [B]	LED-6/12W / 700 mA - 3000 K	1363.5	80
185-9676	symmetric, wide beam [B]	LED-6/12W / 700 mA - 4000 K	1457.5	80
185-7762	symmetric, wide beam [B]	LED-6/18W / 1050 mA - 3000 K	1897.5	80
185-7766	symmetric, wide beam [B]	LED-6/18W / 1050 mA - 4000 K	1985.8	80
185-7760	symmetric, medium beam [M]	LED-6/18W / 1050 mA - 3000 K	2162.6	80
185-7764	symmetric, medium beam [M]	LED-6/18W / 1050 mA - 4000 K	2263.2	80
185-7761	symmetric, very narrow beam [EE]	LED-6/18W / 1050 mA - 3000 K	2046.6	80
185-7765	symmetric, very narrow beam [EE]	LED-6/18W / 1050 mA - 4000 K	2141.8	80
185-7831	symmetric, wide beam [B]	LED-6/12W / 700 mA - 2700 K	1224.8	80
185-7834	symmetric, wide beam [B]	LED-6/18W / 1050 mA - 2700 K	1809.3	80
185-7828	symmetric, medium beam [M]	LED-6/12W / 700 mA - 2700 K	1426.1	80
185-7832	symmetric, medium beam [M]	LED-6/18W / 1050 mA - 2700 K	2062	80
185-7829	symmetric, very narrow beam [EE]	LED-6/12W / 700 mA - 2700 K	1393.8	80
185-7833	symmetric, very narrow beam [EE]	LED-6/18W / 1050 mA - 2700 K	1951.4	80
185-7830	symmetric, very narrow beam, sharp cut-off [EES]	LED-6/12W / 700 mA - 2700 K	1512.7	80

Showing 1 to 21 of 21 entries.

Accessories

Control

Mounting Accessories

Optical Accessories

Part-ID	Title	Specifications
		Text	PDF
430-0013	DALI interface
