FLC311 RAIL66

IP66. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. Mains voltage versions, DALI interface Class I. 1-10 V analogue dimming available on request; refer to accessory listings. 24VDC low voltage versions, 0-10 V analogue dimming (only 9W available) Class III available on request. Including 0.4 m of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system. Optical accessories are factory-installed. To be specified at time of ordering.

Colours

RAL9004 Signal black

RAL9007 Grey aluminium

RAL7016 Anthracite grey

RAL9016 Traffic white

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK08
Ingress Protection	IP66
Corrosion Protection	5CE
Mounting	Including 0.4 m of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	Including 0.4 m of flexible cable

Additional Information

Lifetime

Ta=25° L90B10 > 90000h

Light Distribution

Delivered Lumen

To

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
145-7708	symmetric, wide beam [B]	LED-3/6W / 180 mA - 2700 K	595.4	80
145-7711	symmetric, wide beam [B]	LED-3/6W / 180 mA - 3000 K	595.4	80
145-7714	symmetric, wide beam [B]	LED-3/6W / 180 mA - 4000 K	641.2	80
145-7709	symmetric, wide beam [B]	LED-3/9W / 250 mA - 2700 K	835.8	80
145-7712	symmetric, wide beam [B]	LED-3/9W / 250 mA - 3000 K	835.8	80
145-7715	symmetric, wide beam [B]	LED-3/9W / 250 mA - 4000 K	893.1	80
145-7710	symmetric, wide beam [B]	LED-3/12W / 350 mA - 2700 K	1122.1	80
145-7713	symmetric, wide beam [B]	LED-3/12W / 350 mA - 3000 K	1122.1	80
145-7716	symmetric, wide beam [B]	LED-3/12W / 350 mA - 4000 K	1213.7	80
145-7717	symmetric, medium beam [M]	LED-3/6W / 180 mA - 2700 K	600.4	80
145-7720	symmetric, medium beam [M]	LED-3/6W / 180 mA - 3000 K	600.4	80
145-7723	symmetric, medium beam [M]	LED-3/6W / 180 mA - 4000 K	646.6	80
145-7718	symmetric, medium beam [M]	LED-3/9W / 250 mA - 2700 K	842.9	80
145-7721	symmetric, medium beam [M]	LED-3/9W / 250 mA - 3000 K	842.9	80
145-7724	symmetric, medium beam [M]	LED-3/9W / 250 mA - 4000 K	900.6	80
145-7719	symmetric, medium beam [M]	LED-3/12W / 350 mA - 2700 K	1131.6	80
145-7722	symmetric, medium beam [M]	LED-3/12W / 350 mA - 3000 K	1131.6	80
145-7725	symmetric, medium beam [M]	LED-3/12W / 350 mA - 4000 K	1224	80
145-7726	symmetric, very narrow beam [EE]	LED-3/6W / 180 mA - 2700 K	605.2	80
145-7729	symmetric, very narrow beam [EE]	LED-3/6W / 180 mA - 3000 K	605.2	80
145-7732	symmetric, very narrow beam [EE]	LED-3/6W / 180 mA - 4000 K	651.7	80
145-7727	symmetric, very narrow beam [EE]	LED-3/9W / 250 mA - 2700 K	849.6	80
145-7730	symmetric, very narrow beam [EE]	LED-3/9W / 250 mA - 3000 K	849.6	80
145-7733	symmetric, very narrow beam [EE]	LED-3/9W / 250 mA - 4000 K	907.8	80
145-7728	symmetric, very narrow beam [EE]	LED-3/12W / 350 mA - 2700 K	1140.5	80

Showing 1 to 25 of 63 Entries
