VLR130 [LA10]

Back
Family Spec Sheet
Narrow Distance Narrow Distance
Wide Distance Wide Distance
20W30W40W

IP67. Class I. IK09. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Linear PMMA LED lens, PMMA cover. 4 ft connecting cable, UV stabilized, PVC free. Integral LED driver; separate LED driver available instead, on request at time of order. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation and can be tilted up to 180°.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade, all-aluminium construction
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK09
SchutzartIP67
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral LED driver with DALI Interface
Kabel4 ft of flexible PVC-free cable
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
187-0015asymmetric linear, wallwash [LA10]LED-48/30W / 225 mA - 3000 K3074.880electronic gear7.20
187-0330asymmetric linear, wallwash [LA10]LED-48/30W / 225 mA - 4000 K3074.880electronic gear7.20
187-0550asymmetric linear, wallwash [LA10]LED-48/30W / 225 mA - 2700 K3074.880electronic gear7.20
Showing 1 to 3 of 3 Entries
