FLC300 series

FLC311 RAIL66

Static White

Choose a variant:

RAIL66
Space Frame

Choose a family:

⌀2.28" | FLC301 RAIL66 ⌀3.35" | FLC311 RAIL66 ⌀4.53" | FLC321 RAIL66
Home
Products
RAIL66
FLC311 RAIL66
Family Spec Sheet Installation Instructions More Downloads

IP66. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral EC electronic converter. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. 6-12W / 120-277V / 0-10V Dimming. Including 1.3 ft of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system. Optical accessories are factory-installed. To be specified at time of ordering.

FLC311 RAIL66 Schematics
Colours
RAL9004 Black
RAL9007 Grey Metallic
RAL9016 White
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
Corrosion Protection5CE
MountingIncluding 1.3 ft of flexible cable enclosed in a stainless conduit, in-line connector and mounting clamp for installation to RAIL66 mounting system
Electrical
Ballast / DriverIntegral [ECG] electronic driver 120V-277V
CableIncluding 1.3 ft of flexible cable
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
145-7708symmetric, wide beam [W]LED-3/6W / 180 mA - 2700 K595.480
145-7711symmetric, wide beam [W]LED-3/6W / 180 mA - 3000 K595.480
145-7714symmetric, wide beam [W]LED-3/6W / 180 mA - 4000 K641.280
145-7709symmetric, wide beam [W]LED-3/9W / 250 mA - 2700 K835.880
145-7712symmetric, wide beam [W]LED-3/9W / 250 mA - 3000 K835.880
145-7715symmetric, wide beam [W]LED-3/9W / 250 mA - 4000 K893.180
145-7710symmetric, wide beam [W]LED-3/12W / 350 mA - 2700 K1122.180
145-7713symmetric, wide beam [W]LED-3/12W / 350 mA - 3000 K1122.180
145-7716symmetric, wide beam [W]LED-3/12W / 350 mA - 4000 K1213.780
145-7717symmetric, medium beam [M]LED-3/6W / 180 mA - 2700 K600.480
145-7720symmetric, medium beam [M]LED-3/6W / 180 mA - 3000 K600.480
145-7723symmetric, medium beam [M]LED-3/6W / 180 mA - 4000 K646.680
145-7718symmetric, medium beam [M]LED-3/9W / 250 mA - 2700 K842.980
145-7721symmetric, medium beam [M]LED-3/9W / 250 mA - 3000 K842.980
145-7724symmetric, medium beam [M]LED-3/9W / 250 mA - 4000 K900.680
145-7719symmetric, medium beam [M]LED-3/12W / 350 mA - 2700 K1131.680
145-7722symmetric, medium beam [M]LED-3/12W / 350 mA - 3000 K1131.680
145-7725symmetric, medium beam [M]LED-3/12W / 350 mA - 4000 K122480
145-7726symmetric, very narrow beam [VN]LED-3/6W / 180 mA - 2700 K605.280
145-7729symmetric, very narrow beam [VN]LED-3/6W / 180 mA - 3000 K605.280
145-7732symmetric, very narrow beam [VN]LED-3/6W / 180 mA - 4000 K651.780
145-7727symmetric, very narrow beam [VN]LED-3/9W / 250 mA - 2700 K849.680
145-7730symmetric, very narrow beam [VN]LED-3/9W / 250 mA - 3000 K849.680
145-7733symmetric, very narrow beam [VN]LED-3/9W / 250 mA - 4000 K907.880
145-7728symmetric, very narrow beam [VN]LED-3/12W / 350 mA - 2700 K1140.580
145-7731symmetric, very narrow beam [VN]LED-3/12W / 350 mA - 3000 K1140.580
145-7734symmetric, very narrow beam [VN]LED-3/12W / 350 mA - 4000 K1233.680
145-7738symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/6W / 180 mA - 3000 K606.380
145-7741symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/6W / 180 mA - 4000 K656.880
145-7736symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/9W / 250 mA - 2700 K858.980
145-7739symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/9W / 250 mA - 3000 K858.980
145-7742symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/9W / 250 mA - 4000 K92280
145-7737symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/12W / 350 mA - 2700 K1149.480
145-7740symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/12W / 350 mA - 3000 K1149.480
145-7743symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/12W / 350 mA - 4000 K1237.880
145-7727linear spread, very narrow beam [VN]LED-3/9W / 250 mA - 2700 K756.980
145-7730linear spread, very narrow beam [VN]LED-3/9W / 250 mA - 3000 K756.980
145-7733linear spread, very narrow beam [VN]LED-3/9W / 250 mA - 4000 K808.780
145-7728linear spread, very narrow beam [VN]LED-3/12W / 350 mA - 2700 K1016.180
145-7731linear spread, very narrow beam [VN]LED-3/12W / 350 mA - 3000 K1016.180
145-7734linear spread, very narrow beam [VN]LED-3/12W / 350 mA - 4000 K1099.180
145-7726linear spread, very narrow beam [VN]LED-3/6W / 180 mA - 2700 K539.280
145-7729linear spread, very narrow beam [VN]LED-3/6W / 180 mA - 3000 K539.280
145-7732linear spread, very narrow beam [VN]LED-3/6W / 180 mA - 4000 K580.680
145-7735symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-3/6W / 180 mA - 2700 K606.380
145-7735linear spread, very narrow beam, 'sharp cut-off'LED-3/6W / 180 mA - 2700 K528.480
145-7738linear spread, very narrow beam, 'sharp cut-off'LED-3/6W / 180 mA - 3000 K528.480
145-7741linear spread, very narrow beam, 'sharp cut-off'LED-3/6W / 180 mA - 4000 K572.480
145-7736linear spread, very narrow beam, 'sharp cut-off'LED-3/9W / 250 mA - 2700 K748.580
145-7739linear spread, very narrow beam, 'sharp cut-off'LED-3/9W / 250 mA - 3000 K748.580
Showing 1 to 50 of 63 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
310-92002 Mains outlets (L=45.28)
310-92023 Mains outlets (L=45.28)
310-92103 Mains outlets (L=64.69)
310-92124 Mains outlets (L=64.69)
310-92204 Mains outlets (L=84.65)
310-92226 Mains outlets (L=84.65)
