FLC131 LED POST

Short-Post

Back
Family Spec Sheet
Standard Projector Standard Projector 112 mm 112 mm
Standard Projector Standard Projector 155 mm 155 mm
Standard Projector Standard Projector 193 mm 193 mm

IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation.
Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black). + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS polymer coated stainless steel
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK07
SchutzartIP66
AbdeckungPowdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019
Korrosionsschutz5CE
BefestigungSuitable for installation over a 4" recessed junction box, or direct to short post, planted root, or pipe clamps.

Elektrik

LED TreiberIntegral EC electronic converter in thermally-separated compartment.
Kabel
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
146-0399symmetric, medium beam [M]LED-12/24W / 700 mA - 3000 K2998.680electronic gear5.50
146-0400symmetric, medium beam [M]LED-12/24W / 700 mA - 4000 K3205.480electronic gear5.50
146-0402symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 3000 K3077.980electronic gear5.50
146-0402linear spread, very narrow beam, 'sharp cut-off'LED-12/24W / 700 mA - 3000 K2865.980electronic gear5.50
146-0403symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 4000 K3290.280electronic gear5.50
146-0403linear spread, very narrow beam, 'sharp cut-off'LED-12/24W / 700 mA - 4000 K3063.580electronic gear5.50
146-0494symmetric, wide beam [W]LED-12/24W / 700 mA - 3000 K2709.280electronic gear5.50
146-0495symmetric, wide beam [W]LED-12/24W / 700 mA - 4000 K289680electronic gear5.50
146-0497symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 3000 K2883.780electronic gear5.50
146-0497linear spread, very narrow beam [VN]LED-12/24W / 700 mA - 3000 K2744.280electronic gear5.50
146-0498symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 4000 K3082.580electronic gear5.50
146-0498linear spread, very narrow beam [VN]LED-12/24W / 700 mA - 4000 K2933.480electronic gear5.50
146-0400wallwashLED-12/24W / 700 mA - 4000 K2571.580electronic gear5.50
146-0399wallwashLED-12/24W / 700 mA - 3000 K2405.680electronic gear5.50
146-0796symmetric, wide beam [W]LED-12/24W / 700 mA - 2700 K2522.380electronic gear5.51
146-0922symmetric, medium beam [M]LED-12/24W / 700 mA - 2700 K2791.880electronic gear5.51
146-0951symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 2700 K2684.880electronic gear5.51
146-0971symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 2700 K2865.680electronic gear5.51
146-0922wallwashLED-12/24W / 700 mA - 2700 K2239.780electronic gear5.51
146-0951linear spread, very narrow beam [VN]LED-12/24W / 700 mA - 2700 K2554.980electronic gear5.51
146-0971linear spread, very narrow beam, 'sharp cut-off'LED-12/24W / 700 mA - 2700 K2668.280electronic gear5.51
Showing 1 to 21 of 21 Entries
