ZFT400

388 mm

170 mm

Street and Area Lighting

ZFT430-FT LED

Family Spec Sheet

Post top luminaire with shielded light source and canopy highlight feature. IP66. Class I. IK09. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. PMMA main lens. CAD-optimized indirect optics for superior illumination and glare control. Integral driver in thermally separated compartment. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation. Recommended mounting height 10-20 ft. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

RAL9004 Black

RAL9006 White

RAL9007 Grey Metallic

RAL7016 Anthracite grey

RAL9016 White

RAL8019 Dark Bronze

Powdercoat finish available in 35 different colours

Material

Body	Marine-grade, die-cast aluminum alloy.
Fasteners	PCS polymer coated stainless steel hardware
Gasket	Silicone rubber gasket
Impact Protection	IK09
Ingress Protection	IP66
Finish	Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007, and Dark Bronze RAL8019.
Corrosion Protection	5CE
Mounting	Luminaire requires a 2.99" diameter x 3.15" long pole top tenon

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	30 feet of flexible 18/5 cable
Power Factor	> 0.9
Power Supply	Integral [ECG] LED driver in 120V-277V
Surge Protection	In-line bracket 10kV Surge Protector

Additional Information

Lifetime	Ta=25°/40° L70B50 > 50000h

BUG Rating	Please see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
115-1241	symmetric distribution [C60]	LED-FT-24W (3000K)	2609.8	80
115-1242	symmetric distribution [C60]	LED-FT-24W (4000K)	2721.1	80
115-1283	symmetric distribution [C60]	LED-FT-37W (3000K)	3914.7	80
115-1284	symmetric distribution [C60]	LED-FT-37W (4000K)	4140.4	80
115-1343	symmetric distribution [C60]	LED-FT 12W (3000K)	1267.8	80
115-1344	symmetric distribution [C60]	LED-FT 12W (4000K)	1335.8	80
115-1531	[C50] Type V Short	LED-FT 12W (3000K)	1698	80
115-1532	[C50] Type V Short	LED-FT 12W (4000K)	1789.1	80
115-1535	[C50] Type V Short	LED-FT-24W (3000K)	3495.5	80
115-1536	[C50] Type V Short	LED-FT-24W (4000K)	3644.6	80
115-1537	[C50] Type V Short	LED-FT-37W (3000K)	5243.2	80
115-1538	[C50] Type V Short	LED-FT-37W (4000K)	5545.5	80
115-1582	[C50] Type V Short	LED-FT-12W (2700K)	1590.4	80
115-1583	[C50] Type V Short	LED-FT-24W (2700K)	3354.7	80
115-1584	[C50] Type V Short	LED-FT-37W (2700K)	5090	80
115-1585	symmetric distribution [C60]	LED-FT-12W (2700K)	1187.4	80
115-1586	symmetric distribution [C60]	LED-FT-24W (2700K)	2504.7	80
115-1620	symmetric distribution [C60]	LED-FT-37W (2700K)	3800.3	80
