RFL500-SE

100 mm

460 mm

12 – 72W Upgrade/Repair Kit

Home

Products

Street and Area Lighting

RFL530-SE LED

Family Spec Sheet

Wall and pole mounted luminaire. IP66. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Non-reflecting safety glass lens hinged, tool-less entry. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Luminaire is factory-sealed and does not need to be opened during installation. Recommended mounting height 10-20 ft, depending on wattage and light distribution selected. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

RAL9004 Black

RAL9006 White

RAL9007 Grey Metallic

RAL7016 Anthracite grey

RAL9016 White

RAL8019 Dark Bronze

Powdercoat finish available in 35 different colours

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS Polymer Coated Stainless Steel Hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK07
Ingress Protection	IP66
Finish	Powdercoat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019
Corrosion Protection	5CE
Mounting

Electrical

Ballast / Driver	Integral EC electronic converter
Cable	30 feet of flexible 18/5 cable
Power Factor	> 0.9
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection	In-line bracket 10kV Surge Protector

Additional Information

Lifetime	Ta=25°/40° L90B10 > 90000h

BUG Rating	Please see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

CRI

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
111-0192	[S60] Type III Short	LED-12/24W / 700 mA - 3000 K	3126.9	80
111-0193	[S60] Type III Short	LED-24/48W / 700 mA - 3000 K	6253.8	80
111-0230	[S70] Type II Short	LED-12/24W / 700 mA - 3000 K	2984.1	80
111-0234	[S70] Type II Short	LED-24/48W / 700 mA - 3000 K	5968.1	80
111-0275	[A60] Type IV Very Short	LED-12/24W / 700 mA - 3000 K	2891.7	80
111-0277	[A60] Type IV Very Short	LED-24/48W / 700 mA - 3000 K	5783.5	80
111-0337	[S60] Type III Short	LED-12/24W / 700 mA - 4000 K	3342.6	80
111-0339	[S60] Type III Short	LED-24/48W / 700 mA - 4000 K	6685.1	80
111-0345	[S70] Type II Short	LED-12/24W / 700 mA - 4000 K	3189.9	80
111-0347	[S70] Type II Short	LED-24/48W / 700 mA - 4000 K	6379.7	80
111-0353	[A60] Type IV Very Short	LED-12/24W / 700 mA - 4000 K	3091.2	80
111-0355	[A60] Type IV Very Short	LED-24/48W / 700 mA - 4000 K	6182.3	80
111-0406	[S60] Type III Short	LED-12/12W / 350 mA - 4000 K	1891	80
111-0407	[S60] Type III Short	LED-24/24W / 350 mA - 4000 K	3782	80
111-0408	[S65] Type III Medium	LED-12/12W / 350 mA - 4000 K	1893.1	80
111-0409	[S65] Type III Medium	LED-12/24W / 700 mA - 4000 K	3348	80
111-0410	[S65] Type III Medium	LED-24/24W / 350 mA - 4000 K	3786.2	80
111-0411	[S65] Type III Medium	LED-24/48W / 700 mA - 4000 K	6696.1	80
111-0412	[S70] Type II Short	LED-12/12W / 350 mA - 4000 K	1836.7	80
111-0413	[S70] Type II Short	LED-24/24W / 350 mA - 4000 K	3673.4	80
111-0414	[A60] Type IV Very Short	LED-12/12W / 350 mA - 4000 K	1784.4	80
111-0415	[A60] Type IV Very Short	LED-24/24W / 350 mA - 4000 K	3568.7	80
111-0416	[R65] Type IV Medium	LED-12/12W / 350 mA - 4000 K	1780.6	80
111-0417	[R65] Type IV Medium	LED-12/24W / 700 mA - 4000 K	3084.3	80
111-0418	[R65] Type IV Medium	LED-24/24W / 350 mA - 4000 K	3561.2	80
