LTM400

IP66. Class I. IK10. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate outer lens. Service door with fused cable connecting box. CAD-optimized indirect optics for superior illumination and glare control. 0-10V Dimming comes standard with luminaire. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colors

Material

Body: Luminaire head, base plate and base plate cover constructed in die cast aluminum

Fasteners: PCS Polymer Coated Stainless Steel hardware

Gasket: Silicone rubber gasket

Impact Protection: IK10

Ingress Protection: IP66

Finish: Powder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 and Dark Bronze RAL8019.

Corrosion Protection: 5CE

Mounting: Light column suitable for installation in landscaped areas on concrete foundations, or in landscaped areas using optional planted root, 697-9307

Electrical

Ballast / Driver: Integral EC electronic converter

Cable:

Power Factor:

Power Supply: Integral [ECG] LED driver in 120-277V

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L70B50 > 50000h

BUG Rating: Please see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Light Distribution

Delivered Lumen

Wattage

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
115-1517	symmetric distribution [C60]	LED-FT-17W (3000K)	2071.2	80
115-1518	symmetric distribution [C60]	LED-FT-17W (4000K)	2158.9	80
115-1519	symmetric distribution [C60]	LED-FT-24W (3000K)	2847	80
115-1520	symmetric distribution [C60]	LED-FT-24W (4000K)	2968.4	80
115-1521	[C50] Type V Short	LED-FT-17W (3000K)	2508.1	80
115-1522	[C50] Type V Short	LED-FT-17W (4000K)	2614.3	80
115-1523	[C50] Type V Short	LED-FT-24W (3000K)	3447.6	80
115-1565	[C50] Type V Short	LED-FT-37W (3000K)	5171.3	80
115-1566	[C50] Type V Short	LED-FT-37W (4000K)	5469.5	80
115-1780	symmetric distribution [C60]	LED-FT-17W (2700K)	1980.1	80
115-1781	symmetric distribution [C60]	LED-FT-24W (2700K)	2732.3	80
115-1778	[C50] Type V Short	LED-FT-17W (2700K)	2397.8	80
115-1779	[C50] Type V Short	LED-FT-24W (2700K)	3308.7	80
115-1838	symmetric distribution [C60]	LED-FT-37W (2700K)	4145.7	80
115-1837	[C50] Type V Short	LED-FT-37W (2700K)	5020.2	80

Showing 1 to 15 of 15 Entries
