Tunable White. IP69K. Class I. IK10+. Stainless steel construction. PCS hardware. Optional with Anti-Slip ceramic Coating ASC to DIN 51130 (Trip Classification 10) available on request. Silicone CCG® Controlled Compression Gasket. Safety glass lens; max load 5.5 tons (11,000 lbs). Luminaire can be driven over at low speed. Cable gland with spiral cable bending protection. Factory-sealed termination chamber complete with cable gland and 3 ft of flexible PVC-free, gel-impregnated anti-wicking cable. CAD-optimized optics for superior illumination and glare control. Integral driver, thermally separated. OLC® One LED Concept. Factory-installed LED circuit board. Tunable White technology. DMX Controlled. Gimbal mounted, 360° rotatable and 30° tiltable. The concrete-pour installation blockout is supplied as standard with luminaire. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

ETC140-GB-TW LED TUNABLE WHITE Schematics
Colors
Material

Body: Luminaire body constructed of deep drawn stainless steel. Outer housing composite material.

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK10+

Ingress Protection: IP69K - HIGHEST PROTECTION RATING AVAILABLE

Finish:

Corrosion Protection:

Mounting: Suitable for installation in concrete or earth. Suitable for walk-over and DRIVE-OVER applications. Proper drainage and foundation support must be provided.

Electrical

Ballast / Driver: Integral EC electronic converter

Cable: 3 ft of flexible PVC-free cable

Power Factor: > 0.9

Power Supply: Integral [ECG] electronic driver 120V-277V. DMX controlled, controller to be ordered separately.

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

:

:

Light Distribution

Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
185-3397symmetric, wide beam [W]LED-24/30W / 225 mA - 2200-6000 K2846.880
185-3398symmetric, medium beam [M]LED-24/30W / 225 mA - 2200-6000 K297580
185-3400wallwashLED-24/30W / 225 mA - 2200-6000 K2717.580
Showing 1 to 3 of 3 Entries

Accessories

Part-IDTitlePDFOpen Data
Please select an accessory category
ItemDownloadMail Link
Product Images
Light Distributions
Install Instructions
Manual
WE-EF Technical Information - DMX Wiring Diagram
WE-EF IP69K Ingrades Overview
