RGBW/RGBA Color Changer. IP69K. Class I. IK10+. Stainless steel construction. PCS hardware. Optional with Anti-Slip ceramic Coating ASC to DIN 51130 (Trip Classification 10) available on request. Silicone CCG® Controlled Compression Gasket. Safety glass lens; max load 5.5 tons (11,000 lbs). Luminaire can be driven over at low speed. Cable gland with spiral cable bending protection. Factory-sealed termination chamber complete with cable gland and 3 ft of flexible PVC-free, gel-impregnated anti-wicking cable. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. DMX interface. Gimbal mounted, 360° rotatable and 30° tiltable. 'No tool' removable gear/lens tray. The concrete-pour installation blockout is supplied as standard with luminaire. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

ETC140-GB-CC LED COLOR CHANGER Schematics
Colors
Material

Body: Luminaire body constructed of deep drawn stainless steel. Outer housing composite material.

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK10+

Ingress Protection: IP69K - HIGHEST PROTECTION RATING AVAILABLE

Finish:

Corrosion Protection:

Mounting: Suitable for installation in concrete or earth. Suitable for walk-over and DRIVE-OVER applications. Proper drainage and foundation support must be provided.

Electrical

Ballast / Driver: Integral EC electronic converter

Cable: 3 ft of flexible PVC-free cable

Power Factor: > 0.9

Power Supply: Integral DMX 120V-277V Driver, 50-60 Hz. DMX Controller to be ordered seperately.

Surge Protection:

Additional Information

Lifetime: Ta=25°/40° L90B10 > 90000h

:

:

Light Distribution

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
185-3401symmetric, wide beam [W]LED-24/30W - RGBW/4K2122.220/80
185-3402symmetric, medium beam [M]LED-24/30W - RGBW/4K2199.820/80
185-3404wallwashLED-24/30W - RGBW/4K191520/80
185-3418symmetric, wide beam [W]LED-24/30W - RGBA1833.620
185-3419symmetric, medium beam [M]LED-24/30W - RGBA1900.620
185-3420asymmetric, wallgrazer [A6]LED-24/30W - RGBA1715.120
185-3421wallwashLED-24/30W - RGBA1654.620
