DAC220 LED

DAC220 LED

Family Spec Sheet

IP65. Class I. IK07. Marine-grade, die-cast aluminum alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens, hinged. CAD-optimized optics for superior illumination and glare control. Integral driver in thermally separated compartment. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire. Frame with safety catch. Suitable for installation over recessed junction box. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

DAC220 LED Schematics
Colors
RAL9004 Black
RAL9006 White
RAL9007 Grey Metallic
RAL7016 Anthracite grey
RAL9016 White
RAL8019 Dark Bronze
Powdercoat finish available in 35 different colours
RAL9016 Traffic white
Material
BodyMarine-grade die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone rubber gasket
Impact ProtectionIK07
Ingress ProtectionIP65
FinishPowder coat finish in Black RAL9004, White RAL9016, Grey Metallic RAL9007 or Dark Bronze RAL8019.
Corrosion Protection5CE
Mounting
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
CableTwo cable entries
Power Factor
Power SupplyIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection
Additional Information
LifetimeTa=25°/40° L90B10 > 90000h

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
134-1424symmetric, wide beam [W]LED-12/24W / 700 mA - 3000 K2709.280
134-1425symmetric, medium beam [M]LED-12/24W / 700 mA - 3000 K2998.680
134-1426symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 3000 K2883.780
134-1427symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 3000 K3077.980
134-1428symmetric, wide beam [W]LED-12/24W / 700 mA - 4000 K289680
134-1429symmetric, medium beam [M]LED-12/24W / 700 mA - 4000 K3205.480
134-1430symmetric, very narrow beam [VN]LED-12/24W / 700 mA - 4000 K3082.580
134-1431symmetric, very narrow beam, 'sharp cut-off' [VNS]LED-12/24W / 700 mA - 4000 K3290.280
134-1429wallwash [A20]LED-12/24W / 700 mA - 4000 K2571.580
134-1425wallwash [A20]LED-12/24W / 700 mA - 3000 K2405.680
134-1426linear spread, very narrow beamLED-12/24W / 700 mA - 3000 K2744.280
134-1427linear spread, very narrow beam, 'sharp cut-off'LED-12/24W / 700 mA - 3000 K2865.980
134-1430linear spread, very narrow beamLED-12/24W / 700 mA - 4000 K2933.480
134-1431linear spread, very narrow beam, 'sharp cut-off'LED-12/24W / 700 mA - 4000 K3063.580
134-1425linear spread, medium beam [M]LED-12/24W / 700 mA - 3000 K2944.880
134-1429linear spread, medium beam [M]LED-12/24W / 700 mA - 4000 K3147.980
