PSY414 LED

Back
Family Spec Sheet
600 mm 600 mm
1.000 mm 1.000 mm

IP66. Class I. IK10. Marine-grade, all aluminum construction. Pole section features galvanized steel reinforcement core. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate main lens. CAD-optimized optics for superior illumination and glare control. Integral driver. OLC® One LED Concept. Factory-installed LED circuit board. 0-10V Dimming comes standard with luminaire.
Pre-wired post complete with 10kV surge protector in cable connection box. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Eigenschaften

Material

GehäuseMarine-grade, all-aluminium construction. Pole section features galvanised steel reinforcement core
SchraubenPCS hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK10
SchutzartIP66/IP67
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter
Kabel
Leistungsfaktor
NetzIntegral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
ÜberspannungsschutzIntegral 10kV Surge Protector

Weitere Eigenschaften

LifetimeTa=25°/40° L90B10 > 90000h
BUG RatingPlease see individual Spec Sheets for classification of Backlight, Uplight and Glare.

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
114-0128rectangular asymmetric Type II [R45]LED-3/6W / 700 mA - 3000 K650.880electronic gear29.76
114-0129rectangular asymmetric Type II [R45]LED-3/6W / 700 mA - 4000 K695.780electronic gear29.76
114-0130rectangular asymmetric Type II [R45]LED-3/9W / 1050mA - 3000 K953.580electronic gear29.76
114-0131rectangular asymmetric Type II [R45]LED-3/9W / 1050mA - 4000 K997.880electronic gear29.76
114-0132rectangular asymmetric Type II [R45]LED-3/13W / 1400 mA - 3000 K1219.580electronic gear29.76
114-0133rectangular asymmetric Type II [R45]LED-3/13W / 1400 mA - 4000 K127580electronic gear29.76
114-0184rectangular asymmetric Type II [R45]LED-3/6W / 700 mA - 2700 K60680electronic gear29.76
114-0185rectangular asymmetric Type II [R45]LED-3/9W / 1050 mA - 2700 K909.180electronic gear29.76
114-0186rectangular asymmetric Type II [R45]LED-3/13W / 1400 mA - 2700 K115380electronic gear29.76
Showing 1 to 9 of 9 Entries
