KTY200 series

KTY234 LED II Security Bollard

Static White

Choose a family:

H39.37" | KTY234 LED II H23.62" | KTY234 LED I H39.37" | KTY234 LED II Security Bollard

Home

Products

Bollards and Pathway Luminaires

KTY234 LED Security Bollard

Family Spec Sheet Installation Instructions More Downloads

Impact-Rated Bollard. IP66. Class I. IK10. Marine-grade, all aluminum construction. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Polycarbonate lens. CAD-optimized indirect optics for superior illumination and glare control. Integral driver in thermally separated compartment. Factory-installed LED circuit board. Crash rated for small vehicles travelling up to 40mph (SC40), pick-up vehicles travelling up to 40mph (PU40), and medium-duty vehicles travelling up to 30mph (M30). Luminaire spacing up to 35 ft; ideal for pathway lighting applications. Specify product with 7 Digit product code – Finish Color. Accessories, such as mounting, optical, and electrical, must be specified separately. Example: XXX-XXXX-9004 (Black) + XXX-XXXX (Accessory 1)

Colours

RAL9004 Black

RAL9007 Grey Metallic

RAL9016 White

RAL8019 Dark Bronze

Material

Body	Marine-grade all-aluminum construction
Fasteners	PCS Polymer Coated Stainless Steel Hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK10
Ingress Protection	IP66
Corrosion Protection	5CE

Electrical

Ballast / Driver	Integral EC electronic converter
Power Supply	Integral [ECG] electronic driver 120V-277V. 0-10V dimmable, to be specified with order.
Surge Protection	Integral 10kV Surge Protector

Additional Information

Lifetime	Ta=25°/40° L90B10 > 90000h
Lead Time	This is a new product release and may have an extended lead time.

Light Distribution

Delivered Lumen

Colour Temperature

CRI

Part-ID	Light Distribution	Light Source	Delivered Lumen	CRI	Specifications
					Text	PDF
114-6516	Blank Head [BLANK]	BLANK Head		NA
114-6517	Blank Head [BLANK]	BLANK Head		NA
114-6501	symmetric distribution [C60]	LED-6/18W / 1050 mA - 3000 K	825	80
114-6500	symmetric distribution [C60]	LED-6/18W / 1050 mA - 3000 K	825	80
114-6503	symmetric distribution [C60]	LED-6/18W / 1050 mA - 4000 K	863.4	80
114-6502	symmetric distribution [C60]	LED-6/18W / 1050 mA - 4000 K	863.4	80
114-6505	symmetric distribution [C60]	LED-6/26W / 1400 mA - 3000 K	1055.3	80
114-6504	symmetric distribution [C60]	LED-6/26W / 1400 mA - 3000 K	1055.3	80
114-6507	symmetric distribution [C60]	LED-6/26W / 1400 mA - 4000 K	1103.3	80
114-6506	symmetric distribution [C60]	LED-6/26W / 1400 mA - 4000 K	1103.3	80
114-6509	rectangular, side throw [R65]	LED-3/13W / 1400 mA - 3000 K	664.7	80
114-6508	rectangular, side throw [R65]	LED-3/13W / 1400 mA - 3000 K	664.7	80
114-6511	rectangular, side throw [R65]	LED-3/13W / 1400 mA - 4000 K	694.9	80
114-6510	rectangular, side throw [R65]	LED-3/13W / 1400 mA - 4000 K	694.9	80
114-6512	rectangular, side throw [R65]	LED-3/9W / 1050 mA - 3000 K	519.7	80
114-6513	rectangular, side throw [R65]	LED-3/9W / 1050 mA - 3000 K	519.7	80
114-6515	rectangular, side throw [R65]	LED-3/9W / 1050 mA - 4000 K	543.9	80
114-6514	rectangular, side throw [R65]	LED-3/9W / 1050 mA - 4000 K	543.9	80

Showing 1 to 18 of 18 entries.

Accessories

	Part-ID	Title	Specifications
	300-0461	Planted root ESV4
