STO279 LED

Back
Family Spec Sheet
Standard Depth Standard Depth 120 mm 120 mm 5W 5W
Reduced Depth Reduced Depth 75 mm 75 mm 6W 6W
Reduced Depth Reduced Depth 100 mm 100 mm 9W 9W
AluminiumWStainless Steel

IP66, Class I. Class II on request. IK10. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Polycarbonate main lens. Two cable entries. Factory installed LED circuit board. Integral EC electronic converter. Optional 2200 K version available. To be specified at time of ordering.
A pre-installation blockout is available and recommended for mounting in concrete walls. To be ordered separately.

Eigenschaften

Material

GehäuseMarine-grade die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone rubber gasket
SchlagfestigkeitIK10
SchutzartIP66
AbdeckungPowdercoat finish in RAL7016, RAL9004, RAL9006, RAL9007 and RAL9016
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter
KabelTwo cable entries
Leistungsfaktor
Netz220-240V / 50-60 Hz
Überspannungsschutz1/2 kV

Weitere Eigenschaften

LifetimeTa=25° L80B10 > 54000h
Energy efficiency classC-D (Light source)

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
133-0352diffused distributionLED-9/21W / 500 mA - 3000 K802.580EC2.30
133-0353diffused distributionLED-9/21W / 500 mA - 4000 K857.480EC2.30
133-0447diffused distributionLED-9/21W / 500 mA - 2700 K747.580EC2.30
Showing 1 to 3 of 3 Entries
