IP55, Class I. Class II on request. IK10. Marine-grade die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Polycarbonate main lens. CAD-optimised indirect optics for superior illumination and glare control. Version with emergency lighting on request.
AL500 series

AL534-FT LED

Static White

Choose a family:

AL534-FT LED
Diameter ⌀: 540 mm
H: 750 mm
Family Spec Sheet Installation Instructions More Downloads

IP55, Class I. Class II on request. IK10. Marine-grade die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone rubber gasket. Polycarbonate main lens. CAD-optimised indirect optics for superior illumination and glare control. Version with emergency lighting on request.

AL534-FT LED Schematics
Colours
RAL9004 Signal black
RAL9006 White aluminium
RAL9016 Traffic white
RAL7016 Anthracite grey
RAL9007 Grey aluminium
Material
BodyMarine-grade, die-cast aluminium alloy
LensPolycarbonate lens
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone rubber gasket
Impact ProtectionIK10
Ingress ProtectionIP55
FinishPowdercoat finish in RAL7016, RAL9004, RAL9006, RAL9007 and RAL9016
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter
Power Supply220-240V / 50-60 Hz
Surge Protection6/6 kV (optional SP10)
Additional Information
Part-IDLight DistributionLight SourceRated LumenCRIDownloads
