IP67*, Class I. IK10+. Stainless steel construction including PCS hardware. Silicone rubber gasket. Safety glass lens; max. load 5 tonnes. Luminaire can be driven over at low speed. Factory-sealed termination chamber complete with cable gland and 1,5 m of flexible PVC free cable. Cable gland with spiral cable bending protection. Factory installed LED circuit board. LED boards can be easily removed for upgrading. The optional installation blockout is recommended for mounting. To be ordered separately. The luminaire is not suitable for permanent underwater operation and must be switched off in the event of flooding. Optional with Anti-Slip ceramic Coating ASC to DIN 51130 (Trip Classification 10) available on request. * Additionally tested to IP66, IP67, IP68 0.1 bar 3h, up to 1 m depth according to DIN EN 60598 and IP69K/80° according to DIN EN 60529.

ETC329 LED Schematics
Colors
Stainless Steel
Material
BodyStainless steel construction
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone rubber gasket
Impact ProtectionIK10+
Ingress ProtectionIP67
FinishStainless steel
Corrosion Protection5CE
Mounting
Electrical
Ballast / DriverIntegral EC electronic converter
Cable1.5 m of flexible PVC free cable
Power Factor> 0.9
Power Supply220-240V / 50-60 Hz
Surge Protection6/6 kV
Additional Information
LifetimeTa=25° L90B10 > 90000h
Energy efficiency classE (Light source)

Delivered Lumen

To
Part-IDLight DistributionLight SourceLumenCRIOpen DataPDFIES, LDT, ULD
185-2908symmetric, diffused distributionLED-36/5W/830 - 3000 K124.980
185-2962symmetric, diffused distributionLED-5.5W/740 - 4000 K130.775
