X-LINE4 FIXE Monochrome
Family Spec Sheet Installation Instructions More Downloads

IP66, Classe I, IK06. Profil aluminium anodisé incolore. PMMA clair. Joint silicone. Fixation sur deux équerres en aluminium anodisé. Visserie inox avec traitement anti couple galvanique Delta Seal®. Visière en option en aluminium brut, RAL à déterminer à la commande. Optiques : 2x2°, 2x5°, 2x15°, 2x22,5°, 50x10° Réglette 230V à LED puissance, pour l’éclairage extérieur. NE PAS ENCASTRER.

X-LINE4 FIXE Monochrome Schematics
Colours
tous les RAL disponibles
Material
BodyProfil aluminium anodisé incolore. PMMA clair.
FastenersVisserie imperdable inox avec traitement anti couple galvanique Delta Seal®.
GasketJoint silicone
Impact ProtectionIK08
Ingress ProtectionIP66
Electrical
Ballast / DriverDMX
CableVersion non pilotable, fixe : câble HO7RN-F 3G1.5mm² : phase (marron), neutre (bleu), terre (vert/jaune). Longueur : 150cm.
Power Factor> 0.9
Power SupplyAlimentation et protection contre la foudre et les surtensions intégrée 10kV / 5kA.
Surge Protection10 kV / 5kA
Additional Information
Durée de vieTa=30° L80 B10 > 60 000 heures
GarantieGarantie 5ans : sur module LED et driver (voir les conditions FLUX).

Delivered Lumen

To

Wattage

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
810-0210symmetric linear, very narrow beam [2x2°]LED-FX-6/6W / 350mA - 2700K577.970
810-0215symmetric linear, narrow beam [2x5°]LED-FX-6/6W / 350mA - 2700K530.870
810-0220symmetric linear, medium beam [2x15°]LED-FX-6/6W / 350mA - 2700K46570
810-0225symmetric linear, wide beam [2x22°]LED-FX-6/6W / 350mA - 2700K429.570
810-0230symmetric linear, asymmetric beam [50x10°]LED-FX-6/6W / 350mA - 2700K452.270
810-0420symmetric linear, very narrow beam [2x2°]LED-FX-6/6W / 350mA - 3000K577.970
810-0425symmetric linear, narrow beam [2x5°]LED-FX-6/6W / 350mA - 3000K530.870
810-0430symmetric linear, medium beam [2x15°]LED-FX-6/6W / 350mA - 3000K46570
810-0435symmetric linear, wide beam [2x22°]LED-FX-6/6W / 350mA - 3000K429.570
810-0440symmetric linear, asymmetric beam [50x10°]LED-FX-6/6W / 350mA - 3000K452.270
810-0630symmetric linear, very narrow beam [2x2°]LED-FX-6/6W / 350mA - 4000K616.770
810-0635symmetric linear, narrow beam [2x5°]LED-FX-6/6W / 350mA - 4000K566.470
810-0640symmetric linear, medium beam [2x15°]LED-FX-6/6W / 350mA - 4000K496.270
810-0645symmetric linear, wide beam [2x22°]LED-FX-6/6W / 350mA - 4000K458.370
810-0650symmetric linear, asymmetric beam [50x10°]LED-FX-6/6W / 350mA - 4000K482.570
810-0840symmetric linear, very narrow beam [2x2°]LED-FX-6/6W / 350mA - 6500K658.470
810-0845symmetric linear, narrow beam [2x5°]LED-FX-6/6W / 350mA - 6500K604.770
810-0850symmetric linear, medium beam [2x15°]LED-FX-6/6W / 350mA - 6500K529.770
810-0855symmetric linear, wide beam [2x22°]LED-FX-6/6W / 350mA - 6500K489.370
810-0860symmetric linear, asymmetric beam [50x10°]LED-FX-6/6W / 350mA - 6500K515.270
810-0245symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 2700K1155.970
810-0250symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 2700K1061.670
810-0255symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 2700K93070
810-0260symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 2700K85970
810-0265symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 2700K904.470
810-0455symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 3000K1155.970
810-0460symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 3000K1061.670
810-0465symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 3000K93070
810-0470symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 3000K85970
810-0475symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 3000K904.470
810-0665symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 4000K1233.370
810-0670symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 4000K1132.770
810-0675symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 4000K992.470
810-0680symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 4000K916.670
810-0685symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 4000K96570
810-0875symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 6500K1316.770
810-0880symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 6500K1209.370
810-0885symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 6500K1059.570
810-0890symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 6500K978.670
810-0895symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 6500K1030.370
810-0280symmetric linear, very narrow beam [2x2°]LED-FX-24/24W / 350mA - 2700K2311.770
810-0285symmetric linear, narrow beam [2x5°]LED-FX-24/24W / 350mA - 2700K2123.170
810-0290symmetric linear, medium beam [2x15°]LED-FX-24/24W / 350mA - 2700K1860.170
810-0295symmetric linear, wide beam [2x22°]LED-FX-24/24W / 350mA - 2700K1718.170
810-0300symmetric linear, asymmetric beam [50x10°]LED-FX-24/24W / 350mA - 2700K1808.970
810-0490symmetric linear, very narrow beam [2x2°]LED-FX-24/24W / 350mA - 3000K2311.770
810-0495symmetric linear, narrow beam [2x5°]LED-FX-24/24W / 350mA - 3000K2123.170
810-0500symmetric linear, medium beam [2x15°]LED-FX-24/24W / 350mA - 3000K1860.170
810-0505symmetric linear, wide beam [2x22°]LED-FX-24/24W / 350mA - 3000K1718.170
810-0510symmetric linear, asymmetric beam [50x10°]LED-FX-24/24W / 350mA - 3000K1808.970
Showing 1 to 50 of 239 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
891-0805Visière X-LINE4 L. 187 mm.
891-0810Visière X-LINE4 L. 337 mm.
891-0815Visière X-LINE4 L. 637 mm.
891-0820Visière X-LINE4 L. 937 mm.
891-0825Visière X-LINE4 L. 1237 mm.
891-0830Visière X-LINE4 L. 1537 mm.
