l73 mm | X-LINE4 RGBW DMX
Accueil
Produits
Linéaires
X-LINE4 RGBW DMX
Fiche technique de la famille Instructions d'installation Autres téléchargements

IP66, Classe I, IK06. Profil aluminium anodisé incolore. PMMA clair. Joint silicone. Fixation sur deux équerres en aluminium anodisé. Visserie inox avec traitement anti couple galvanique Delta Seal®. Visière en option en aluminium brut, RAL à déterminer à la commande. Optiques : 2x6°, 2x11°, 2x23°, 40x15° Réglette 230V à LED puissance, pour l’éclairage extérieur. NE PAS ENCASTRER.

X-LINE4 RGBW DMX Schematics
Couleurs
tous les RAL disponibles
Description du matériel
CorpsProfil aluminium anodisé incolore. PMMA clair.
VisserieVisserie imperdable inox avec traitement anti couple galvanique Delta Seal®.
JointJoint silicone
IKIK08
IPIP66
Description électrique
DriverDMX
CâbleVersion pilotable en DMX : câble CONNECT SYSTEM. Longueur : 50cm.
Facteur de puissance> 0.9
Alimentation électriqueAlimentation et protection contre la foudre et les surtensions intégrée 10kV / 5kA.
Protection contre les surtensions10 kV / 5kA
Informations complémentaires
Durée de vieTa=30° L80 B10 > 60 000 heures
GarantieGarantie 5ans : sur module LED et driver (voir les conditions FLUX).

Données en sortie de luminaire

To

Puissance

To
Code produitDistribution photométriqueSource lumineuseDonnées en sortie de luminaireIRCCaractéristiquesPhotométrie
TextePDF
810-7395symmetric linear, narrow beam [2x6°]LED-FX-24/17W / 330/250mA - RGB-3K875.20
810-7430symmetric linear, medium beam [2x11°]LED-FX-48/34W / 330/250mA - RGB-3K1604.50
810-7465symmetric linear, wide beam [2x23°]LED-FX-72/51W / 330/250mA - RGB-3K2490.20
810-7500symmetric linear, asymmetric beam [40x15°]LED-FX-96/68W / 330/250mA - RGB-3K3299.10
810-7515symmetric linear, narrow beam [2x6°]LED-FX-120/85W / 330/250mA - RGB-3K4375.80
810-7400symmetric linear, medium beam [2x11°]LED-FX-24/17W / 330/250mA - RGB-3K802.20
810-7435symmetric linear, wide beam [2x23°]LED-FX-48/34W / 330/250mA - RGB-3K1660.20
810-7470symmetric linear, asymmetric beam [40x15°]LED-FX-72/51W / 330/250mA - RGB-3K2474.30
810-7485symmetric linear, narrow beam [2x6°]LED-FX-96/68W / 330/250mA - RGB-3K3500.60
810-7525symmetric linear, medium beam [2x11°]LED-FX-120/85W / 330/250mA - RGB-3K4150.40
810-7405symmetric linear, wide beam [2x23°]LED-FX-24/17W / 330/250mA - RGB-3K830.10
810-7440symmetric linear, asymmetric beam [40x15°]LED-FX-48/34W / 330/250mA - RGB-3K1649.50
810-7455symmetric linear, narrow beam [2x6°]LED-FX-72/51W / 330/250mA - RGB-3K2625.50
810-7490symmetric linear, medium beam [2x11°]LED-FX-96/68W / 330/250mA - RGB-3K3208.90
810-7520symmetric linear, wide beam [2x23°]LED-FX-120/85W / 330/250mA - RGB-3K4011.20
810-7410symmetric linear, asymmetric beam [40x15°]LED-FX-24/17W / 330/250mA - RGB-3K824.80
810-7425symmetric linear, narrow beam [2x6°]LED-FX-48/34W / 330/250mA - RGB-3K1750.30
810-7460symmetric linear, medium beam [2x11°]LED-FX-72/51W / 330/250mA - RGB-3K2406.70
810-7495symmetric linear, wide beam [2x23°]LED-FX-96/68W / 330/250mA - RGB-3K3320.30
810-7530symmetric linear, asymmetric beam [40x15°]LED-FX-120/85W / 330/250mA - RGB-3K4123.90
810-7575symmetric linear, narrow beam [2x6°]LED-FX-24/17W / 330/250mA - RGB-4K938.50
810-7610symmetric linear, medium beam [2x11°]LED-FX-48/34W / 330/250mA - RGB-4K1720.60
810-7645symmetric linear, wide beam [2x23°]LED-FX-72/51W / 330/250mA - RGB-4K2670.50
810-7680symmetric linear, asymmetric beam [40x15°]LED-FX-96/68W / 330/250mA - RGB-4K3537.90
810-7695symmetric linear, narrow beam [2x6°]LED-FX-120/85W / 330/250mA - RGB-4K4692.60
810-7580symmetric linear, medium beam [2x11°]LED-FX-24/17W / 330/250mA - RGB-4K860.30
810-7615symmetric linear, wide beam [2x23°]LED-FX-48/34W / 330/250mA - RGB-4K1780.30
810-7650symmetric linear, asymmetric beam [40x15°]LED-FX-72/51W / 330/250mA - RGB-4K2653.50
810-7665symmetric linear, narrow beam [2x6°]LED-FX-96/68W / 330/250mA - RGB-4K3754.10
810-7700symmetric linear, medium beam [2x11°]LED-FX-120/85W / 330/250mA - RGB-4K4301.60
810-7585symmetric linear, wide beam [2x23°]LED-FX-24/17W / 330/250mA - RGB-4K890.20
810-7620symmetric linear, asymmetric beam [40x15°]LED-FX-48/34W / 330/250mA - RGB-4K17690
810-7635symmetric linear, narrow beam [2x6°]LED-FX-72/51W / 330/250mA - RGB-4K2815.60
810-7670symmetric linear, medium beam [2x11°]LED-FX-96/68W / 330/250mA - RGB-4K3441.20
810-7705symmetric linear, wide beam [2x23°]LED-FX-120/85W / 330/250mA - RGB-4K4450.90
810-7590symmetric linear, asymmetric beam [40x15°]LED-FX-24/17W / 330/250mA - RGB-4K884.50
810-7605symmetric linear, narrow beam [2x6°]LED-FX-48/34W / 330/250mA - RGB-4K18770
810-7640symmetric linear, medium beam [2x11°]LED-FX-72/51W / 330/250mA - RGB-4K2580.90
810-7675symmetric linear, wide beam [2x23°]LED-FX-96/68W / 330/250mA - RGB-4K3560.70
810-7710symmetric linear, asymmetric beam [40x15°]LED-FX-120/85W / 330/250mA - RGB-4K4422.40
Affichage de 1 à 40 sur 40 résultats

Accessories

Code produitTitreCaractéristiques
TextePDF
891-0805Visière X-LINE4 L. 187 mm.
891-0810Visière X-LINE4 L. 337 mm.
891-0815Visière X-LINE4 L. 637 mm.
891-0820Visière X-LINE4 L. 937 mm.
891-0825Visière X-LINE4 L. 1237 mm.
891-0830Visière X-LINE4 L. 1537 mm.
