X-LINE4 Serie

X-LINE4 DMX Monochrome

Static White
Colour Changer
Tunable White

Familienauswahl:

l73 mm | X-LINE4 DALI Monochrome l73 mm | X-LINE4 DMX Monochrome l73 mm | X-LINE4 FIXE Monochrome
Startseite
Produkte
Linéaires
X-LINE4 DMX Monochrome
Familiendatenblatt Installationsanleitung Weitere Downloads

IP66, Classe I, IK06. Profil aluminium anodisé incolore. PMMA clair. Joint silicone. Fixation sur deux équerres en aluminium anodisé. Visserie inox avec traitement anti couple galvanique Delta Seal®. Visière en option en aluminium brut, RAL à déterminer à la commande. Optiques : 2x2°, 2x5°, 2x15°, 2x22,5°, 50x10° Réglette 230V à LED puissance, pour l’éclairage extérieur. NE PAS ENCASTRER.

X-LINE4 DMX Monochrome Schematics
Farben
tous les RAL disponibles
Materialinformationen
GehäuseProfil aluminium anodisé incolore. PMMA clair.
SchraubenVisserie imperdable inox avec traitement anti couple galvanique Delta Seal®.
DichtungJoint silicone
SchlagfestigkeitIK08
SchutzartIP66
KorrosionsbeständigkeitTraitement anticorrosion avant peinture poudre polyester
Elektrische Informationen
Netzgerät / VorschaltgerätDMX
KabelProfil aluminium anodisé incolore. PMMA clair.
Leistungsfaktor> 0.9
NetzAlimentation et protection contre la foudre et les surtensions intégrée 10kV / 5kA.
Überspannungsschutz10 kV / 5kA
Weitere Informationen
Durée de vieTa=30° L80 B10 > 60 000 heures
GarantieGarantie 5ans : sur module LED et driver (voir les conditions FLUX).

Bemessungslichtstrom

To

Leistung

To
ArtikelnummerLichtverteilungLichtquelleBemessungslichtstromCRISpezifikationenPhotometrie
TextPDF
810-1865symmetric linear, medium beam [2x15°]LED-FX-60/44W / 350mA - AMBRE1529.30
810-4245symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 2700K1155.970
810-4250symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 2700K1061.670
810-4255symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 2700K93070
810-4260symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 2700K85970
810-4265symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 2700K904.470
810-4280symmetric linear, very narrow beam [2x2°]LED-FX-24/24W / 350mA - 2700K2311.770
810-4285symmetric linear, narrow beam [2x5°]LED-FX-24/24W / 350mA - 2700K2123.170
810-4290symmetric linear, medium beam [2x15°]LED-FX-24/24W / 350mA - 2700K1860.170
810-4300symmetric linear, asymmetric beam [50x10°]LED-FX-24/24W / 350mA - 2700K1808.970
810-4315symmetric linear, very narrow beam [2x2°]LED-FX-36/36W / 350mA - 2700K3467.670
810-4320symmetric linear, narrow beam [2x5°]LED-FX-36/36W / 350mA - 2700K3184.770
810-4325symmetric linear, medium beam [2x15°]LED-FX-36/36W / 350mA - 2700K2790.170
810-4330symmetric linear, wide beam [2x22°]LED-FX-36/36W / 350mA - 2700K2577.170
810-4335symmetric linear, asymmetric beam [50x10°]LED-FX-36/36W / 350mA - 2700K2713.370
810-4350symmetric linear, very narrow beam [2x2°]LED-FX-48/48W / 350mA - 2700K4623.470
810-4355symmetric linear, narrow beam [2x5°]LED-FX-48/48W / 350mA - 2700K4246.370
810-4360symmetric linear, medium beam [2x15°]LED-FX-48/48W / 350mA - 2700K3720.170
810-4365symmetric linear, wide beam [2x22°]LED-FX-48/48W / 350mA - 2700K3436.170
810-4370symmetric linear, asymmetric beam [50x10°]LED-FX-48/48W / 350mA - 2700K3617.770
810-4385symmetric linear, very narrow beam [2x2°]LED-FX-60/60W / 350mA - 2700K5779.370
810-4390symmetric linear, narrow beam [2x5°]LED-FX-60/60W / 350mA - 2700K5307.870
810-4395symmetric linear, medium beam [2x15°]LED-FX-60/60W / 350mA - 2700K4650.270
810-4400symmetric linear, wide beam [2x22°]LED-FX-60/60W / 350mA - 2700K4295.270
810-4405symmetric linear, asymmetric beam [50x10°]LED-FX-60/60W / 350mA - 2700K4522.170
810-4455symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 3000K1155.970
810-4460symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 3000K1061.670
810-4465symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 3000K93070
810-4470symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 3000K85970
810-4475symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 3000K904.470
810-4490symmetric linear, very narrow beam [2x2°]LED-FX-24/24W / 350mA - 3000K2311.770
810-4500symmetric linear, medium beam [2x15°]LED-FX-24/24W / 350mA - 3000K1860.170
810-4505symmetric linear, wide beam [2x22°]LED-FX-24/24W / 350mA - 3000K1718.170
810-4510symmetric linear, asymmetric beam [50x10°]LED-FX-24/24W / 350mA - 3000K1808.970
810-4525symmetric linear, very narrow beam [2x2°]LED-FX-36/36W / 350mA - 3000K3467.670
810-4530symmetric linear, narrow beam [2x5°]LED-FX-36/36W / 350mA - 3000K3184.770
810-4535symmetric linear, medium beam [2x15°]LED-FX-36/36W / 350mA - 3000K2790.170
810-4540symmetric linear, wide beam [2x22°]LED-FX-36/36W / 350mA - 3000K2577.170
810-4545symmetric linear, asymmetric beam [50x10°]LED-FX-36/36W / 350mA - 3000K2713.370
810-4495symmetric linear, narrow beam [2x5°]LED-FX-24/24W / 350mA - 3000K2123.170
810-4560symmetric linear, very narrow beam [2x2°]LED-FX-48/48W / 350mA - 3000K4623.470
810-4565symmetric linear, narrow beam [2x5°]LED-FX-48/48W / 350mA - 3000K4246.370
810-4575symmetric linear, wide beam [2x22°]LED-FX-48/48W / 350mA - 3000K3436.170
810-4580symmetric linear, asymmetric beam [50x10°]LED-FX-48/48W / 350mA - 3000K3617.770
810-4595symmetric linear, very narrow beam [2x2°]LED-FX-60/60W / 350mA - 3000K5779.370
810-4600symmetric linear, narrow beam [2x5°]LED-FX-60/60W / 350mA - 3000K5307.870
810-4605symmetric linear, medium beam [2x15°]LED-FX-60/60W / 350mA - 3000K4650.270
810-4610symmetric linear, wide beam [2x22°]LED-FX-60/60W / 350mA - 3000K4295.270
810-4615symmetric linear, asymmetric beam [50x10°]LED-FX-60/60W / 350mA - 3000K4522.170
810-4665symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 4000K1233.370
Einträge 1 bis 50 von 200.

Accessories

ArtikelnummerTitelSpezifikationen
TextPDF
891-0805Visière X-LINE4 L. 187 mm.
891-0810Visière X-LINE4 L. 337 mm.
891-0815Visière X-LINE4 L. 637 mm.
891-0820Visière X-LINE4 L. 937 mm.
891-0825Visière X-LINE4 L. 1237 mm.
891-0830Visière X-LINE4 L. 1537 mm.
