X-LINE4 DALI Monochrome
Fiche technique de la famille Instructions d'installation Autres téléchargements

IP66, Classe I, IK06. Profil aluminium anodisé incolore. PMMA clair. Joint silicone. Fixation sur deux équerres en aluminium anodisé. Visserie inox avec traitement anti couple galvanique Delta Seal®. Visière en option en aluminium brut, RAL à déterminer à la commande. Optiques : 2x2°, 2x5°, 2x15°, 2x22,5°, 50x10° Réglette 230V à LED puissance, pour l’éclairage extérieur. NE PAS ENCASTRER.

X-LINE4 DALI Monochrome Schematics
Couleurs
Description du matériel
CorpsProfil aluminium anodisé incolore. PMMA clair.
VisserieVisserie imperdable inox avec traitement anti couple galvanique Delta Seal®.
JointJoint silicone
IKIK08
IPIP66
Description électrique
DriverDALI
CâbleVersion pilotable en DALI : câble HO7RN-F 5G1.5mm² (Bleu, marron, vert/jaune, gris, noir). Longueur : 150cm.
Facteur de puissance> 0.9
Alimentation électriqueAlimentation et protection contre la foudre et les surtensions intégrée 10kV / 5kA.
Protection contre les surtensions10 kV / 5kA
Informations complémentaires
Durée de vieTa=30° L80 B10 > 60 000 heures
GarantieGarantie 5ans : sur module LED et driver (voir les conditions FLUX).

Flux lumineux émis

RéférenceDistribution lumineuseSource lumineuseFlux lumineux émisIRCSpécificationsPhotométrie
TextePDF
810-2245symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 2700K1155.970
810-2250symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 2700K1061.670
810-2255symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 2700K93070
810-2260symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 2700K85970
810-2265symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 2700K904.470
810-2280symmetric linear, very narrow beam [2x2°]LED-FX-24/24W / 350mA - 2700K2311.770
810-2285symmetric linear, narrow beam [2x5°]LED-FX-24/24W / 350mA - 2700K2123.170
810-2290symmetric linear, medium beam [2x15°]LED-FX-24/24W / 350mA - 2700K1860.170
810-2295symmetric linear, wide beam [2x22°]LED-FX-24/24W / 350mA - 2700K1718.170
810-2300symmetric linear, asymmetric beam [50x10°]LED-FX-24/24W / 350mA - 2700K1808.970
810-2315symmetric linear, very narrow beam [2x2°]LED-FX-36/36W / 350mA - 2700K3467.670
810-2320symmetric linear, narrow beam [2x5°]LED-FX-36/36W / 350mA - 2700K3184.770
810-2325symmetric linear, medium beam [2x15°]LED-FX-36/36W / 350mA - 2700K2790.170
810-2330symmetric linear, wide beam [2x22°]LED-FX-36/36W / 350mA - 2700K2577.170
810-2335symmetric linear, asymmetric beam [50x10°]LED-FX-36/36W / 350mA - 2700K2713.370
810-2350symmetric linear, very narrow beam [2x2°]LED-FX-48/48W / 350mA - 2700K4623.470
810-2355symmetric linear, narrow beam [2x5°]LED-FX-48/48W / 350mA - 2700K4246.370
810-2360symmetric linear, medium beam [2x15°]LED-FX-48/48W / 350mA - 2700K3720.170
810-2365symmetric linear, wide beam [2x22°]LED-FX-48/48W / 350mA - 2700K3436.170
810-2370symmetric linear, asymmetric beam [50x10°]LED-FX-48/48W / 350mA - 2700K3617.770
810-2385symmetric linear, very narrow beam [2x2°]LED-FX-60/60W / 350mA - 2700K5779.370
810-2390symmetric linear, narrow beam [2x5°]LED-FX-60/60W / 350mA - 2700K5307.870
810-2395symmetric linear, medium beam [2x15°]LED-FX-60/60W / 350mA - 2700K4650.270
810-2400symmetric linear, wide beam [2x22°]LED-FX-60/60W / 350mA - 2700K4295.270
810-2405symmetric linear, asymmetric beam [50x10°]LED-FX-60/60W / 350mA - 2700K4522.170
810-2455symmetric linear, very narrow beam [2x2°]LED-FX-12/12W / 350mA - 3000K1155.970
810-2460symmetric linear, narrow beam [2x5°]LED-FX-12/12W / 350mA - 3000K1061.670
810-2465symmetric linear, medium beam [2x15°]LED-FX-12/12W / 350mA - 3000K93070
810-2470symmetric linear, wide beam [2x22°]LED-FX-12/12W / 350mA - 3000K85970
810-2475symmetric linear, asymmetric beam [50x10°]LED-FX-12/12W / 350mA - 3000K904.470
810-2490symmetric linear, very narrow beam [2x2°]LED-FX-24/24W / 350mA - 3000K2311.770
810-2495symmetric linear, narrow beam [2x5°]LED-FX-24/24W / 350mA - 3000K2123.170
810-2500symmetric linear, medium beam [2x15°]LED-FX-24/24W / 350mA - 3000K1860.170
810-2505symmetric linear, wide beam [2x22°]LED-FX-24/24W / 350mA - 3000K1718.170
810-2510symmetric linear, asymmetric beam [50x10°]LED-FX-24/24W / 350mA - 3000K1808.970
810-2525symmetric linear, very narrow beam [2x2°]LED-FX-36/36W / 350mA - 3000K3467.670
810-2530symmetric linear, narrow beam [2x5°]LED-FX-36/36W / 350mA - 3000K3184.770
810-2535symmetric linear, medium beam [2x15°]LED-FX-36/36W / 350mA - 3000K2790.170
810-2540symmetric linear, wide beam [2x22°]LED-FX-36/36W / 350mA - 3000K2577.170
810-2545symmetric linear, asymmetric beam [50x10°]LED-FX-36/36W / 350mA - 3000K2713.370
810-2560symmetric linear, very narrow beam [2x2°]LED-FX-48/48W / 350mA - 3000K4623.470
810-2565symmetric linear, narrow beam [2x5°]LED-FX-48/48W / 350mA - 3000K4246.370
810-2570symmetric linear, medium beam [2x15°]LED-FX-48/48W / 350mA - 3000K3720.170
810-2575symmetric linear, wide beam [2x22°]LED-FX-48/48W / 350mA - 3000K3436.170
810-2580symmetric linear, asymmetric beam [50x10°]LED-FX-48/48W / 350mA - 3000K3617.770
810-2595symmetric linear, very narrow beam [2x2°]LED-FX-60/60W / 350mA - 3000K5779.370
810-2600symmetric linear, narrow beam [2x5°]LED-FX-60/60W / 350mA - 3000K5307.870
810-2605symmetric linear, medium beam [2x15°]LED-FX-60/60W / 350mA - 3000K4650.270
810-2610symmetric linear, wide beam [2x22°]LED-FX-60/60W / 350mA - 3000K4295.270
810-2615symmetric linear, asymmetric beam [50x10°]LED-FX-60/60W / 350mA - 3000K4522.170
Affichage de 1 à 50 sur 200 entrées.
