FLA400 series

FLA461 LED Wall bracket

Static White

Choose a family:

L385×W260 mm | FLA441 LED Wall bracket L530×W350 mm | FLA461 LED Wall bracket
Home
Products
Surface-Mounted Wall Luminaires
FLA461 LED Wall bracket
Family Spec Sheet Installation Instructions More Downloads

IP66 . IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens, hinged. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised OLC® One LED Concept optics for superior illumination and glare control.

FLA461 LED Wall bracket Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
FinishPowdercoat finish in RAL9004, RAL9006, RAL9007, RAL7016 and RAL9016
Corrosion Protection5CE
MountingSuitable for downlighting, facade and uplighting applications
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Additional Information

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
108-7770asymmetric, forward throw [A60]LED-36/72W / 700 mA - 3000 K7798.980
108-7771asymmetric, forward throw [A60]LED-36/72W / 700 mA - 4000 K8336.880
108-7780asymmetric, forward throw [A60]LED-36/108W / 1050 mA - 3000 K11563.980
108-7781asymmetric, forward throw [A60]LED-36/108W / 1050 mA - 4000 K12101.880
108-7768rectangular, side throw [R65]LED-36/72W / 700 mA - 3000 K7621.480
108-7769rectangular, side throw [R65]LED-36/72W / 700 mA - 4000 K814780
108-7778rectangular, side throw [R65]LED-36/108W / 1050 mA - 3000 K11300.680
108-7779rectangular, side throw [R65]LED-36/108W / 1050 mA - 4000 K11826.380
108-7764asymmetric, side throw [S65]LED-36/72W / 700 mA - 3000 K8365.580
108-7765asymmetric, side throw [S65]LED-36/72W / 700 mA - 4000 K8942.480
108-7774asymmetric, side throw [S65]LED-36/108W / 1050 mA - 3000 K1240480
108-7775asymmetric, side throw [S65]LED-36/108W / 1050 mA - 4000 K12980.980
Showing 1 to 12 of 12 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
310-9109Universal mouting flange UMF30
ItemDownload
Product Images
Photometrics
Installation Instructions
WE-EF Revit Files - FLA461 LED
