FLA400 series

FLA441 LED Wall bracket

Static White

Choose a family:

L385×W260 mm | FLA441 LED Wall bracket L530×W350 mm | FLA461 LED Wall bracket
Home
Products
Surface-Mounted Wall Luminaires
FLA441 LED Wall bracket
Family Spec Sheet Installation Instructions More Downloads

IP66 . IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens, hinged. Silicone CCG® Controlled Compression Gasket. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised OLC® One LED Concept optics for superior illumination and glare control.

FLA441 LED Wall bracket Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK08
Ingress ProtectionIP66
FinishPowdercoat finish in RAL9004, RAL9006, RAL9007, RAL7016 and RAL9016
Corrosion Protection5CE
MountingSuitable for downlighting, facade and uplighting applications
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Additional Information

Delivered Lumen

To
Part-IDLight DistributionLight SourceDelivered LumenCRISpecificationsPhotometrics
TextPDF
108-7749asymmetric, forward throw [A60]LED-18/36W / 700 mA - 3000 K3899.580
108-7750asymmetric, forward throw [A60]LED-18/36W / 700 mA - 4000 K4168.480
108-7759asymmetric, forward throw [A60]LED-18/54W / 1050 mA - 3000 K578280
108-7760asymmetric, forward throw [A60]LED-18/54W / 1050 mA - 4000 K6051.180
108-7747rectangular, side throw [R65]LED-18/36W / 700 mA - 3000 K3810.780
108-7748rectangular, side throw [R65]LED-18/36W / 700 mA - 4000 K4073.580
108-7757rectangular, side throw [R65]LED-18/54W / 1050 mA - 3000 K5650.380
108-7758rectangular, side throw [R65]LED-18/54W / 1050 mA - 4000 K5913.380
108-7743asymmetric, side throw [S65]LED-18/36W / 700 mA - 3000 K4182.780
108-7744asymmetric, side throw [S65]LED-18/36W / 700 mA - 4000 K4471.280
108-7753asymmetric, side throw [S65]LED-18/54W / 1050 mA - 3000 K620280
108-7754asymmetric, side throw [S65]LED-18/54W / 1050 mA - 4000 K6490.780
Showing 1 to 12 of 12 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
310-9110Universal mounting flange UMF20
