FLC230 LED [FP]
Family Spec Sheet Installation Instructions More Downloads

Profile Projector [FP] for framing applications, polygon shape. Spherical/triple flat convex lens system. IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. Two cable glands. Second gland for through wiring. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. Optional 2200 K version is available on request.

FLC230 LED [FP] Schematics
Colours
RAL9004 Signal black
RAL9007 Grey aluminium
RAL7016 Anthracite grey
RAL9016 Traffic white
Material
BodyMarine-grade, die-cast aluminium alloy
FastenersPCS Polymer Coated Stainless Steel Hardware
GasketSilicone CCG® Controlled Compression Gasket
Impact ProtectionIK07
Ingress ProtectionIP66
Corrosion Protection5CE
Electrical
Ballast / DriverIntegral EC electronic converter in thermally-separated compartment
Power Factor> 0.9
Power Supply220-240V / 50-60 Hz
Surge Protection6/6 kV (optional SP10)
Additional Information
LifetimeTa=25° L70B50 > 50000h

Rated Lumen

Wattage

To
Part-IDLight DistributionLight SourceRated LumenCRISpecificationsPhotometrics
TextPDF
139-3001_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-36W / 850 mA - 2700 K288680
139-3001_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-36W / 850 mA - 2700 K2580.280
139-3003_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-36W / 850 mA - 3000 K2911.780
139-3003_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-36W / 850 mA - 3000 K2603.280
139-3005_minsymmetric Framing-Projector [FP] - max aperture angleLED-FT-36W / 850 mA - 4000 K3120.780
139-3005_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-36W / 850 mA - 4000 K2790.180
139-3002_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-48W / 1100 mA - 2700 K3684.780
139-3002_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-48W / 1100 mA - 2700 K3294.380
139-3004_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-48W / 1100 mA - 3000 K3719.180
139-3004_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-48W / 1100 mA - 3000 K332580
139-3006_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-48W / 1100 mA - 4000 K3985.480
139-3006_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-48W / 1100 mA - 4000 K3563.180
Showing 1 to 12 of 12 entries.

Accessories

Part-IDTitleSpecifications
TextPDF
270-9038Short post EM1-M16
