FLC220 LED [FP]

Back
Standard Colours
Tunable White
Colour Changer
Family Spec Sheet
Adjustable rectangular light area Adjustable rectangular light area Frame Frame
Adjustable round spot area Adjustable round spot area Zoom Zoom
Freeform shape projection Freeform shape projection Gobo Gobo
6W18 – 26W24 – 37W36 – 52W

Profile Projector [FP] for framing applications, polygon shape. Spherical and aspherical, double flat convex lens system.
IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG_R_ Controlled Compression Gasket. Safety glass lens. Two cable glands. Second gland for through wiring. Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberIntegral EC electronic converter in thermally-separated compartment
Kabel
Leistungsfaktor> 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25° L70B50 > 50000h

Lichtverteilung

Lichtstrom (lm)

Farbtemperatur (K)

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
139-2130_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-24W / 700 mA - 3000 K1587.780EC8.20
139-2131_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-24W / 700 mA - 4000 K1656.480EC8.20
139-2118_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-37W / 1050 mA - 3000 K2153.680EC8.20
139-2125_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-37W / 1050 mA - 4000 K2245.280EC8.20
139-2510_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-24W / 700 mA - 2700 K1541.980EC8.20
139-2513_minsymmetric Framing-Projector [FP] - min aperture angleLED-FT-37W / 1050 mA - 2700 K2091.780EC8.20
139-2510_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-24W / 700 mA - 2700 K1541.980EC8.20
139-2130_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-24W / 700 mA - 3000 K1836.180EC8.20
139-2131_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-24W / 700 mA - 4000 K1915.680EC8.20
139-2513_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-37W / 1050 mA - 2700 K2091.780EC8.20
139-2125_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-37W / 1050 mA - 4000 K2596.680EC8.20
139-2118_maxsymmetric Framing-Projector [FP] - max aperture angleLED-FT-37W / 1050 mA - 3000 K2490.680EC8.20
Showing 1 to 12 of 12 Entries
