FLC200

150 mm

FLC210-CC

190 mm

RGBW/RGBA Colour Changer. RGBW (white in 4000 K, 3000 K available on request) and RGBA. IP66. Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG_R_ Controlled Compression Gasket. Two cable glands. Integral EC electronic converter in thermally separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC_R_ One LED Concept. LED circuit board with WE-EF Colour Boost Technology. DMX Interface. For other control interface options to suit specific project requirements, contact WE-EF.

Colors

Material

Body: Marine-grade, die-cast aluminium alloy

Fasteners: PCS Polymer Coated Stainless Steel Hardware

Gasket: Silicone CCG® Controlled Compression Gasket

Impact Protection: IK07

Ingress Protection: IP66

Finish:

Corrosion Protection: 5CE

Mounting:

Electrical

Ballast / Driver: DMX

Cable:

Power Factor: > 0.9

Power Supply: 220-240V / 50-60 Hz

Surge Protection:

Additional Information

Lifetime: Ta=25° L90B10 > 90000h

Light Distribution

Delivered Lumen

Colour Temperature

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
139-1929	symmetric, wide beam [B]	LED-12/48W - RGBW/4K	2983	20/80
139-1913	symmetric, medium beam [M]	LED-12/48W - RGBW/4K	3205	20/80
139-2420	symmetric, very narrow beam, sharp cut-off [EES]	LED-4x6/42W - RGBW/4K	2183.4	20/80
139-1914	linear spread, narrow beam [E]	LED-12/48W - RGBW/4K	2865.3	20/80
139-1913	wallwash	LED-12/48W - RGBW/4K	2599.1	20/80
139-2137	symmetric, wide beam [B]	LED-12/48W - RGBA	2412.8	20
139-2139	symmetric, medium beam [M]	LED-12/48W - RGBA	2592.2	20
139-2138	symmetric, narrow beam [E]	LED-12/48W - RGBA	2542.7	20
139-2139	wallwash	LED-12/48W - RGBA	2102.2	20
139-2138	linear spread, narrow beam [E]	LED-12/48W - RGBA	2317.5	20
139-2422	symmetric, very narrow beam, sharp cut-off [EES]	LED-4x6/42W - RGBA	1949.5	20
139-1914	symmetric, narrow beam [E]	LED-12/48W - RGBW/4K	3143.7	20/80

Showing 1 to 12 of 12 Entries
