FLC220-TW LED

Back
Standard Colours
Tunable White
Family Spec Sheet
Standard Projector Standard Projector 75 mm 75 mm
Standard Projector Standard Projector 150 mm 150 mm
Standard Projector Standard Projector 190 mm 190 mm
Standard Projector Standard Projector 260 mm 260 mm
Standard Projector Standard Projector 340 mm 340 mm
Standard Projector Standard Projector 385 mm 385 mm

Tunable white projector. IP66. Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Safety glass lens. Silicone CCG® Controlled Compression Gasket. Two cable glands.
Integral EC electronic converter in thermally-separated compartment. Advanced thermal management protects LEDs while optimising lumens output. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. LED circuit board with Tunable White Technology. DALI Interface . For other control interface options to suit specific project requirements, contact WE-EF.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung

Elektrik

LED TreiberDALI
Kabel
Leistungsfaktor
Netz
Überspannungsschutz

Weitere Eigenschaften

LifetimeTa=25° L90B10 > 90000h

Lichtverteilung

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
139-2041symmetric, wide beam [B]LED-6/22W - 2200-6000 K2043.580EC4.30
139-2043symmetric, narrow beam [E]LED-6/22W - 2200-6000 K2080.380EC4.30
139-2042symmetric, medium beam [M]LED-6/22W - 2200-6000 K2027.480EC4.30
139-2043linear spread, narrow beam [E]LED-6/22W - 2200-6000 K1893.980EC4.30
Showing 1 to 4 of 4 Entries
