FLC210-TW LED

Back
Standard Colours
Tunable White
Family Spec Sheet
Standard Projector Standard Projector 75 mm 75 mm
Standard Projector Standard Projector 150 mm 150 mm
Standard Projector Standard Projector 190 mm 190 mm
Standard Projector Standard Projector 260 mm 260 mm
Standard Projector Standard Projector 340 mm 340 mm
Standard Projector Standard Projector 385 mm 385 mm

Tunable white projector. IP66, Class I. IK07. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. Silicone CCG® Controlled Compression Gasket. Safety glass lens. One cable gland. Second gland for through-wiring on request.
Integral EC electronic converter in thermally-separated compartment. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Factory-installed LED circuit board with Tunable White Technology. DALI interface. For other control interface options to suit specific project requirements, contact WE-EF.

Eigenschaften

Material

GehäuseMarine-grade, die-cast aluminium alloy
SchraubenPCS Polymer Coated Stainless Steel Hardware
FarbenPending
DichtungSilicone CCG® Controlled Compression Gasket
SchlagfestigkeitIK07
SchutzartIP66
Abdeckung
Korrosionsschutz5CE
Befestigung-

Elektrik

LED TreiberDALI
KabelOne cable gland, second gland for through-wiring on request
Leistungsfaktor> 0.9
Netz220-240V / 50-60 Hz
Überspannungsschutz

Weitere Eigenschaften

Ta=25° L90B10 > 90000h

Lichtverteilung

Artikel­nummerLicht­verteilungLicht­quelleBemessungs­lichtstromCRIVorschalt­gerätGewicht (kg)Open Data (txt)Daten­blattIES, LDT, ULD
139-2417symmetric, wide beam [B]LED-3/11W - 2200-6000 K953.580EC4.00
139-2418symmetric, medium beam [M]LED-3/11W - 2200-6000 K963.480EC4.00
139-2419symmetric, narrow beam [E]LED-3/11W - 2200-6000 K980.780EC4.00
Showing 1 to 3 of 3 Entries
