PFL540 LED

IP66, Class I. IK08. Marine-grade, die-cast aluminium alloy. 5CE superior corrosion protection including PCS hardware. RFC™ Reflection Free Contour main lens. Silicone CCG® Controlled Compression Gasket. Luminaire is factory-sealed and does not need to be opened during installation. Integral electronic converter with DALI interface. Advanced thermal management protects LEDs while optimising lumens output. Removable LED boards for upgrading. CAD-optimised optics for superior illumination and glare control. OLC® One LED Concept. Optional 2200 K version up to max. 1050mA available. To be specified at time of ordering. Including 0.5 m cable with a cable connector. Maximum spacing for streetlighting applications depends on wattage and light distribution: 5.5 to 9 times the mounting height. Wild-Light options available on request.

Colors

RAL9004 Signal black

RAL9006 White aluminium

RAL9007 Grey aluminium

RAL7016 Anthracite grey

RAL9016 Traffic white

RAL8019 Grey brown

Powdercoat finish available in 35 different colours

Material

Body	Marine-grade, die-cast aluminium alloy
Fasteners	PCS Polymer Coated Stainless Steel Hardware
Gasket	Silicone CCG® Controlled Compression Gasket
Impact Protection	IK08
Ingress Protection	IP66
Finish	Powdercoat finish in black RAL9004, grey aluminium RAL9007, white aluminium RAL9006 or white RAL9016
Corrosion Protection	5CE
Mounting	Maximum spacing for streetlighting applications depends on wattage and light distribution: 5.5 to 9 times the mounting height.

Electrical

Ballast / Driver	Integral electronic converter with DALI interface
Cable	Including 0.5 m cable with a cable connector
Power Factor	> 0.9
Power Supply	220-240V / 50-60 Hz
Surge Protection

Additional Information

Lifetime	Ta=25° L90B10 > 90000h

BUG Rating	Please see individual Spec Sheets for classification of Backlight, Uplight and Glare

Light Distribution

Delivered Lumen

To

Wattage

To

Colour Temperature

CRI

Part-ID	Light Distribution	Light Source	Lumen	CRI	Open Data	PDF	IES, LDT, ULD
108-0822	asymmetric, side throw [S70]	LED-48/96W / 700 mA - 4000 K	13171.5	80
108-0823	asymmetric, side throw [S70]	LED-36/72W / 700 mA - 4000 K	9878.6	80
108-0824	asymmetric, side throw [S70]	LED-24/48W / 700 mA - 4000 K	6585.8	80
108-0825	asymmetric, side throw [S70]	LED-24/72W / 1050 mA - 4000 K	9478.2	80
108-0826	asymmetric, side throw [S70]	LED-36/108W / 1050 mA - 4000 K	14217.3	80
108-0827	asymmetric, side throw [S70]	LED-48/144W / 1050 mA - 4000 K	18956.4	80
108-0828	asymmetric, side throw [S65]	LED-24/48W / 700 mA - 4000 K	6763.7	80
108-0829	asymmetric, side throw [S65]	LED-24/72W / 1050 mA - 4000 K	9816.6	80
108-0830	asymmetric, side throw [S65]	LED-36/72W / 700 mA - 4000 K	10145.6	80
108-0831	asymmetric, side throw [S65]	LED-36/108W / 1050 mA - 4000 K	14725	80
108-0832	asymmetric, side throw [S65]	LED-48/96W / 700 mA - 4000 K	13527.4	80
108-0833	asymmetric, side throw [S65]	LED-48/144W / 1050 mA - 4000 K	19633.3	80
108-0949	asymmetric, side throw [S60]	LED-24/48W / 700 mA - 4000 K	6701	80
108-0950	asymmetric, side throw [S60]	LED-36/72W / 700 mA - 4000 K	10051.6	80
108-0951	asymmetric, side throw [S60]	LED-48/96W / 700 mA - 4000 K	13402.1	80
108-0952	asymmetric, side throw [S60]	LED-24/72W / 1050 mA - 4000 K	9628.2	80
108-0953	asymmetric, side throw [S60]	LED-36/108W / 1050 mA - 4000 K	14442.3	80
108-0954	asymmetric, side throw [S60]	LED-48/144W / 1050 mA - 4000 K	19256.4	80
108-0955	rectangular, side throw [R65]	LED-24/48W / 700 mA - 4000 K	6295.7	80
108-0956	rectangular, side throw [R65]	LED-36/72W / 700 mA - 4000 K	9443.5	80
108-0957	rectangular, side throw [R65]	LED-48/96W / 700 mA - 4000 K	12591.3	80
108-0958	rectangular, side throw [R65]	LED-24/72W / 1050 mA - 4000 K	9104.5	80
108-0959	rectangular, side throw [R65]	LED-36/108W / 1050 mA - 4000 K	13656.7	80
108-0960	rectangular, side throw [R65]	LED-48/144W / 1050 mA - 4000 K	18209	80
108-0961	asymmetric, forward throw [A60]	LED-24/48W / 700 mA - 4000 K	6145.6	80

Showing 1 to 25 of 133 Entries
